Series LOP-R Vacuum Lubricant Regeneration Oil Purifier

Series LOP-R Vacuum Lubricant Regeneration Oil Purifier thumbnail-1
Series LOP-R Vacuum Lubricant Regeneration Oil Purifier thumbnail-2
Series LOP-R Vacuum Lubricant Regeneration Oil Purifier thumbnail-3
Series LOP-R Vacuum Lubricant Regeneration Oil Purifier photo-1
Series LOP-R Vacuum Lubricant Regeneration Oil Purifier photo-2
Series LOP-R Vacuum Lubricant Regeneration Oil Purifier photo-3
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Certification:
CE, ISO, WSF
After-sales Service Provided:
Engineers available to service machinery overseas
Contact Supplier Request Quote Chat Now
FuooTech Oil Filtration And Oil Purifier Manufacturing Group
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai, Guangzhou, any other ports in China
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Certification CE, ISO, WSF
After-sales Service Provided Engineers available to service machinery overseas
Series LOP-R vacuum Lubricant Regeneration oil purifier is used to treat and regenerate various industrial hydraulic lube oils, especially for those contains high acid value.
Series LOP-R vacuum Lubricant Regeneration oil purifier is widely applied in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway etc. And it is the most reliable, versatile, durable, and user-friendly purification systems in the industry nowadays.
This Oil Regeneration machine can not only rapidly remove water, gas and impurities from lubrication oil, but also remove the carbon, deep oxides, acid, solvent and pitch, etc… So it can highly boost the oil’s value, making the oil more suitable for the lubricating system.
Oil Result after Regeneration
Moisture   (water content)
≤80 PPM
 (remove 100% of free water and 99.5%of   dissolved/emulsified water)
Gas Content
≤0.01%
Suspended Particles   (filtration precision)
≤ 3 micron
Demulsification
New oil≤15min, running oil≤30min
Acid value
≤ 0.03 mg KOH/g
Cleanliness
≤NAS 1638-Grade 5

The features of Series LOP-R Vacuum Lubricant Regeneration Oil Purifier

  1. Advanced dehydration and gas separating system, duplex 3D stereo-evaporation technology ensures fast speed removal of water and gas in the oil.

  2. Strong ability of breaking emulsification, remove more free water and dissolved water content.

  3. Strong ability of removing particle & impurities through multi-stage high precision filters.

  4. Advanced automatic medium cooling system, improving working efficiency.

  5. Electric control panel with vacuum indicator, pressure indicator, digtal type temperature controlling system with indicator and automatic shut-down system.

  6. Top-quality components, good mechanical performance and workmanship ensure years of maintenance-free operation and performance

  7. Double-infared oil level controlling system control the oil level automatically.

  8. This machine has a special oil regeneration device which can regenerate the seriously deteriorated oil by removing the polarity materials, such as the deep oxides, free carbon, and acid in the oil effectively.

Technical specifications of Series LOP-R Vacuum Lubricant Regeneration Oil Purifier
Item
Unit
LOP-R-10
LOP-R -20
LOP-R -30
LOP-R -50
LOP-R -100
LOP-R -150
LOP-R -200
LOP-R -300
Flow rate
L/H
600
1200
1800
3000
6000
9000
12000
18000
Vacuum degree
Mpa
-0.06 ~ - 0.095
Working pressure
Mpa
≤0.4
Temperature Control Range
℃
0 ~ 100
Operation Temperature
℃
50 ~ 70
Demulsification
Min
New oil≤15min,   running oil≤30min
Power supply
380 VAC, 50 Hz, 3   Phase (or as per required)
Working noise
DB (A)
≤ 65 ~ 90
Electric heating   power
KW
18
24
26
30
48
60
96
135
Total electric   power
KW
19.3
25.3
27.6
32.6
56
69
106.5
147
Inlet (outlet)   caliber
mm
Ф25
Ф25
Ф25
Ф32
Ф42
Ф50
Ф50
Ф60
Dimension
 (L × W × H)
mm
1500 x1000
x 1500
1550
x1050   x1600
1600
x1050
x1650
1600
x 1150
x1700
1750 x1250
x 1800
1900
x1600
x1950
1900
x1700
x2000
2100
x1700
x2100
Weight
Kg
450
550
600
750
850
1000
1200
1500
Note:    1. The dimension and weight will be changed with changing of technical specs.
             2. All the specs can be customized according to client's requirements.

    For more info, pls don't hesitate to contact us.
