Help CenterFloat Type Liquid Level Switch
Related Products
Technical Parameter:
Connection type: flange DN50~DN150, G2" or G11/2" thread, G3/8" or G1/2" thread
Diameter pipe: 14mm, 16mm, 20mm
Max length: 6000mm
Switching state: SPST; SPDT
Switch No.: max 8 switches
Contact nodes: AO-normally open (250VAC 0.5A 20W)
AC-normally closed (250VAC 0.5A 20W)
BO- normally open (250VAC 1.0A 250W)
BC- normally closed (250VAC 1.0A 250W)
C-transformation (250VAC 1.0A 60W)
Life time: ≤1x109
Tolerance: ±8±2 mm
Mdistance of tow switches: 50mm
Transmitting: above2000mm
Medium density: above 0.5g/cm3
Working presure: PN2.5~PN160
Working temperature:-40~80°C; -40~120°C
High temperature type: ≤150°C
Float ball: φ30~ φ120
Material: 304,316L, 321, 1Cr18Ni9Ti, 0Cr18Ni9Ti, 00Cr17Ni14Mo2, Titanium
Installation of no vertical: ≤±25°
Protection class: IP65
Explosion-proof: ExiaII CT5
