Piezoresistive Analog Output Pressure Transmitter
Negotiable
MOQ: 30 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
cj
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
cj
Place of Origin
China
| Piezoresistive Analog Output Pressure Transmitter |
| Features |
| ·Reliable performance, easy application |
| ·Short protection and reverse polarity protection |
| ·Measure gauge, absolute and sealed gauge |
| ·Intrinsic safe version, conforming to Standard ExiaⅡCT6 of GB3836.4 |
| ·Ship-use product conforming to CCS Rules of Classification of Sea-going Steel Ships (2006) |
| Introduction |
| it is piezo-resistive pressure transmitter with zero and span adjustable. It uses high stable and reliable pressure sensor and special circuit board to produce transmitter, and performance is good and reliable. MPM489 pressure transmitter is used for measure and control of petroleum, chemi-industry, electric power, hydrology and flow pressure measure, etc. |
| Specification |
| ·Pressure range: -0.1…0～0.01…100MPa |
| ·Overpressure: 1.5 times FS or 110MPa (min. value is valid) |
| ·Pressure type: gauge/ absolute / sealed gauge |
| ·Process connection: M20×1.5 male waterline seal (or on your demand) |
| ·Accuracy: 0.5％FS |
| ·Long term stability: max. ±0.3%FS/year |
| ·Zero thermal drift: 0.1%FS/℃(≤100kPa)；0.05%FS/℃(＞100kPa) |
| ·Span thermal drift: 0.1%FS/℃(≤100kPa)；0.05%FS/℃(＜100kPa) |
| ·Compensation temp.: 0～50℃ |
| ·Application temp.: -30～80℃， intrinsic safe version: -10～60℃ , EXD: -20～60℃ |
| ·Storage temp.: -40～120℃ |
| ·Power supply: 11～28VDC，intrinsic safe version supplied by safe barrier |
