Pressure Transmitter
Model: CJBP155
Description
CJBP155 series are especially for air compressor. The cost-performance is high. It utilizes the newest technology and assembles high performance circuit. It is small profile, has strong capability of dampproof and anti-electromagnetic interference. Mainly apply in fields of air compressor, vacuum equipment, oil pressure equipment.
Features
Wide measurement range,
Full stainless steel
Protection: IP65
ExiaIIBT6 Anti-explosion
CE, CMC certification
Application
Petroleum industry, chemical industry, metallurgy industry, electric power, hydrology etc.
Boats&ships and aviation industry
Hydraulic pressure and pneumatic control system .
Performance Parameters
Measurement Range: |
0~5Mpa |
Proof pressure: |
≤1.5X rated pressure |
Pressure type: |
Gauge, absolute , sealed gauge |
Accuracy: |
±0.25%（typical） ±0.5%（Max.） |
Long stability: |
±0.1%F.S/year（typical） ±0.2%F.S/year（Max.） |
Temperature Error- Zero: |
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa） |
Temperature Error -Span: |
±0.03%F.S/℃（≤100KPa） ±0.02%F.S/℃（＞100KPa） |
Operating Temperature Range |
-20℃~80℃ |
Storage Temperature Range: |
-40℃~120℃ |
Power supply: |
5VDC、12VDC、24VDC |
Output signal: |
4～20mA 0.5～4.5VDC,1～5/10V |
Pressure port: |
M20×1.5, G1/4 or customize |
Housing material: |
1Cr18Ni9Ti stainless steel |
Diaphragm material: |
316L |
O-ring: |
Fluororubber |
Cable: |
Polyethylene |
|
Insulation resistance: Explosion Grade: |
100MΩ, 100VDC IP65 |
