Brushless electric screwdriver： This electric screw driver also adopts the brushless motor,compared with the Swiss brushless motor electric screwdriver,It owns a wide torque range,Its price is more affordable,So its cost-effective is very high.On the other hand,It is more durable than the electric screw with ordinary motor,You should never need to worry about the problem of carbon powder overflow,also avoid troubles of replacing the carbon brush frequently,therefore,It is widely used in the automation equipment as a torque driver.
1) The highest speed design of 2000rpm offers two years warranty for free repair service.
2) This kind brushless electric screwdriver adopts the high efficiency brushless motor,Long lifetime and unsurpassed durability.
3) No need to replace carbon brush,Reduce the cost of enterprise expenditure effectively.
4) Brushless motor design is available in the clean room operation.
5) The excellent gold plating switch can raise the contact spot life up to 10 million times and reduce the maintenance cost.
6) No any carbon dust flowing out not only responses to the earth environment protection but also reduces air pollution.
Model & Specification: Suffix “F”(High speed type) | |||||||
Model |
Power controller |
Working vol. |
Torque range |
Speed |
Screwdriver bits |
Applicable screw(mm) |
|
Lever type |
(DCV) |
(kgf.cm²) |
(rpm)±10% |
Machine thread(Ø) |
Tapping thread(Ø) |
||
BS-2000 |
APS-301A AM-30 |
9~30 |
0.3~2.0 |
700~1000 |
Ø4、Ø5、SH1/4 |
1.0~2.2 |
1.0~2.0 |
BS-3000 |
APS-301A AM-30 |
9~30 |
0.5~5.0 |
700~1000 |
Ø4、Ø5、SH1/4 |
1.0~2.6 |
1.2~2.3 |
BS-4000 BS-4000F |
APS-301A AM-30 |
9~30 |
2.0~12 |
700~1000 1400~2000 |
Ø4、Ø5、SH1/4 |
1.4~3.0 |
1.4~2.6 |
BS-6000 |
APS-301A AM-30 |
9~30 |
2.0~16 |
700~1000 |
Ø4、Ø5、SH1/4 |
2.2~4.0 |
2.0~3.2 |
BS-6500 |
APS-301A AM-30 |
9~30 |
4.0~20 |
700~1000 |
Ø4、Ø5、SH1/4 |
2.6~4.2 |
2.3~3.5 |
BS-6800 |
APM-301A AM-30 |
9~30 |
5.0~25 |
500~700 |
Ø4、Ø5、SH1/4 |
3.0~5.0 |
2.6~4.0 |
Available controller: | |||||||
Outline |
Model |
Working vol. |
Output vol. |
Dimension |
Weight |
Load current |
Safety certificate |
(ACV) |
(DCV) |
(mm) |
(g) |
(A) |
|||
|
APS-301A |
100~240 |
20~30 |
164x64x42 |
300 |
Max.4.5 |
CB,CE,UL, CCC,ROHS, REACH |
|
APM-301A |
100~240 |
20~30 |
172x84x46 |
380 |
Max.4.5 |
CB,CE,UL, CCC,ROHS, REACH |
|
AM-30 |
100~240 |
20~30 |
172x84x61 |
450 |
Max.4.5 |
CB,CE,UL, CCC,ROHS, REACH |
