High Quality Industrial Suction Hose Hydrualic Rubber Hose
Construction:
Tube:Black SBR.
Reinforcement:Multiple textile plies with wire helix.
Cover:Black synthetic rubber; Wrapped finish.
Temperature range: -40° to +180° Fahrenheit.
Application:
It is a large diameter suction and discharge hose designed to handle drilling mud, mild chemicals, oily, water, petroleum waste and sewage in oil field applications such as a flexible, vibration-dampening connection between the slush pump and mud pit during rotary well drilling. The hose construction incorporates a wire helix that provides full suction capability, kink resistance, and a path to conduct a static electrical charge to ground. The cover is resistant to abrasion, oil and weathering.
Specification:
| Part No. | ID (in) |
ID (mm) |
Reinf. Plies |
OD (in) |
OD (mm) |
Approx. Wt. (lbs/ft) |
Approx. Wt. (kg/ft) |
Min. Bend Rad (in) |
Min. Bend Rad (mm) |
Max. Rec. WP (psi) |
Max Lg (ft) |
| HAPPY-10000 | 10 | 254 | 4 | 11.375 | 288.9 | 19.5 | 8.85 | 60 | 1524 | 150 | 50 |
| HAPPY-12000 | 12 | 304.8 | 4 | 13.375 | 339.7 | 24.8 | 11.25 | 72 | 1828.8 | 150 | 50 |
| HAPPY-4000 | 4 | 101.6 | 4 | 5 | 127 | 4.7 | 2.13 | 24 | 609.6 | 150 | 100 |
| HAPPY-6000 | 6 | 152.4 | 4 | 7.125 | 181 | 8.5 | 3.9 | 36 | 914.4 | 150 | 100 |
| HAPPY-8000 | 8 | 203.2 | 4 | 9.25 | 235 | 12.8 | 5.81 | 48 | 1219.2 | 150 | 100 |
Our Services
We can offer OEM Services.
We can provide FREE SAMPLE for our customers.
We can crimp hose assembly for our customers.
We welcome clients to visit our factory leading to better understanding of our production.
FAQ's
Q1. Do you produce smooth or cloth wrapped cover?
A. Both, we can produce both cover, which depends on customer's request.
Q2. Do you produce embossed marking?
A. Yes, we do provide embossed and printing markings with different color.
Q3. Can you produce product with my own brand?
A. Yes, we have been offering OEM services for more than 13 years.
Q4. Does your product have different color hose?
A. Yes, we currently provide black, grey, red, blue and yellow.
Q5. How long does my order take to be delivered?
A. It usually takes 5 to 30 days, which generally depends on the quantity of your order and our storage.
Our principle:
Excellent quality , Fast delivery, Integrity service.
For any inquiries,please contact us directly !
