Product Description
| Place of Origin | Hebei, China (Mainland) |
| Brand Name | ENUO |
| Model Number | SAE / DIN |
| Material | NBR |
| Reinforcement | High Tensile Steel Wire |
| Surface | Smooth or Wrapped |
| Certification | ISO9001, CCS, MA etc |
| Color | Blue Yellow Green Black Red etc. |
| Temperature | -40C~+100C |
| Cover | Abrasion Weather Resistant Synthetic Rubber |
| Keyword | hydraulic hose |
Product Application of SAE 100 R1 High Pressure 602 Wire Braid Excavator brand names hydraulic Rubber hose
Our products are popular in the demestic market, at the same time, we enjoyed a good reputation from the foreign customers.
This hoses are extensively used to mining, metallurgical, oil, project machinery, chemical, agriculture field. E.g. Mine hydraulic fluid, oil exploration, crane, forging metallurgy, mining equipment, ships, injection molding machinery, agricultural machinery and various machines tools.
SPECIFICATIONS FOR SAE 100 R6 / EN 854 1TE | ||||||
|
DN MM |
Hose I.D INCH |
Hose O.D MM |
Working Pressure BAR |
Burst Pressure BAR |
Min.Bend Radius MM |
Weight KG/M |
5 |
3/16 |
11.0 |
35 |
140 |
35 |
0.930 |
6 |
1/4 |
12.6 |
35 |
120 |
45 |
0.117 |
8 |
5/16 |
14.1 |
35 |
120 |
65 |
0.135 |
10 |
3/8 |
15.8 |
35 |
120 |
75 |
0.165 |
12 |
1/2 |
19.4 |
35 |
120 |
90 |
0.215 |
16 |
5/8 |
23.0 |
35 |
120 |
115 |
0.285 |
19 |
3/4 |
26.0 |
35 |
120 |
140 |
0.325 |
25 |
1 |
32.0 |
35 |
120 |
150 |
0.430 |
SPECIFICATIONS FOR SAE 100 R3 / EN 854 3TE | ||||||
|
DN MM |
Hose I.D INCH |
Hose O.D MM |
Working Pressure BAR |
Burst Pressure BAR |
Min.Bend Radius MM |
Weight KG/M |
5 |
3/16 |
13.5 |
105 |
420 |
75 |
0.160 |
6 |
1/4 |
14.5 |
87 |
350 |
75 |
0.180 |
8 |
5/16 |
16.8 |
84 |
335 |
100 |
0.270 |
10 |
3/8 |
18.6 |
78 |
315 |
100 |
0.310 |
12 |
1/2 |
22.5 |
70 |
280 |
125 |
0.450 |
16 |
5/8 |
26.2 |
61 |
245 |
140 |
0.530 |
19 |
3/4 |
29.5 |
52 |
210 |
150 |
0.720 |
25 |
1 |
36 |
39 |
157 |
205 |
0.900 |
32 |
1 1/4 |
43.5 |
26 |
105 |
250 | 1.070 |
Main Features OF High Pressure Fiber Braid Rubber Hydraulic Hose SAE 100 R3 EN 854 3TE
Tube: oil resistant synthetic rubber
Reinforcement: One high resistance texitel braid
Cover: Abrasion and weather resistant synthetic rubber
Temperanture range: -40°c to +100°c
More contact
| Company : | ENUO X AND H GROUP LIMITED | |||||
| Contact person: | ADA WANG | |||||
| Telephone number: | 0086-17710253197 | |||||
| Email: | ada910926@gmail.com |
|||||
