Rubber Air Hose - 20Bar / 300Psi
1. Used for delivery of compressed air and inert gas in mining,civil enginnerring,and factory.
2. Character: The hose body is soft and handiness;tube has good performance of air tight;cover has good performance of anti-aging and wear-resistance.The burst pressure is at least fourfold than the working pressure.
3.The I.D,O.D,W.P and B.P of Rubber Air Compressor Hose is able to produce as per the customers' requirements;the maximum I.D is up to 500mm;the maximum length is up to 60 M.
Features
superior oil resistance, heat resistance and aging resistance by using special synthetic rubber.
high pressure resistance and superior impulse resistance.
superior bonding in hose internal, soft use and small deformation under pressure.
superior kink resistance and fatigue resistance and longer services life.
| Hose I.D | Hose O.D | Working Pressure | Burst Pressure | Min. Bend Radius | Weight | |||
| Inch | mm | mm | Bar | Psi | Bar | Psi | mm | Kg/m |
| 6 | 1/4" | 13 | 20 | 300 | 60 | 900 | 35 | 0.15 |
| 8 | 5/16" | 15 | 20 | 300 | 60 | 900 | 50 | 0.18 |
| 10 | 3/8" | 16 | 20 | 300 | 60 | 900 | 60 | 0.21 |
| 12 | 1/2" | 21 | 20 | 300 | 60 | 900 | 70 | 0.3 |
| 16 | 5/8" | 25 | 20 | 300 | 60 | 900 | 80 | 0.4 |
| 19 | 3/4" | 29 | 20 | 300 | 60 | 900 | 110 | 0.47 |
| 25 | 1" | 36 | 20 | 300 | 60 | 900 | 130 | 0.64 |
| 32 | 1 1/4 | 44 | 20 | 300 | 60 | 900 | 230 | 1.06 |
| 38 | 1 1/2 | 50 | 20 | 300 | 60 | 900 | 270 | 1.24 |
| 51 | 2 | 65 | 20 | 300 | 60 | 900 | 400 | 1.63 |
