blankets making machine

Specifications

blankets making machine which use Imported materials , high accuracy and long life infare protection and high security

>The blanket making machine Adopting digital control program.
>Saddles and rollers driven by Panasonic servo devices.
>The revolution of the spindle controlled by Panasonic frequency conversion control devices.
>360 degrees quilting, Machine come with 300 quilting patterns for your choice

>Easy pattern drawing system enable you finish the pattern design in a few minutes.

>Tack and jump function included
>stitches length 2mm-6mm adjustable.

>Pattern compensation

>Adjustable pressing plate lifting mechanism enables you quilt a broad range of material thickness.
>Simulation display of quilting.

>Thread break detectors.

>Automatic needle raising and location brake system.

>Error problem detection system.

> Emergency sensors safety device

>Improved quilting software control system allows more precise and stable quilting operations.

>Improved fabric loading system :The fabric-loading motor provides tension control and ensure the quilting effect .



TECHNICAL DATA

			Max.needles		Quilting	RUNNING	NEEDLE	RATING		NEEDLE	QUILTING
SPECIFICIATION	Size ( L*W*H)	WEIGHT	quantity	STROKE	width	RATE	DISTANCE	POWER	VOLTAGE	MODEL	THICKNESS
CS64INCH 2NEEDLE ROW	3600*1100*1650mm	2300KG	128pcs	203.2mm	1626mm	200-500R/M	25.4mm	3.5kw	380V	16/19	≤30mm ≤400g/m2
CS64INCH 3NEEDLE ROW	3800*1200*1650mm	2600KG	192pcs	304.8mm	1626mm	200-500R/M	25.4mm	3.5kw	380V	16/19	≤30mm ≤400g/m2
