Meca Quilting Machine CS64

Meca Quilting Machine CS64 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CHISHING
Model Number:
CS64
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name CHISHING
Model Number CS64

Specifications

ChiShing quilting compare with meca machine the price is very competitive

CS64 chishing computerzed quilting machine has following features

 Main features:

  1. This quilting machine Adopting digital control program.
  2. Saddles and rollers driven by Panasonic servo devices.
  3. The revolution of the spindle controlled by Panasonic frequency conversion control devices.
  4. Large number of built-in quilting patterns for your choice.
  5. Easy and quick pattern design .
  6. 360 degrees and 180 degrees quilting
  7. Tack and jump function included  .
  8. stitches between 2mm-6mm adjustable.
  9. Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick
    materials.
  10. Simulation display of quilting.
  11. Automatic needle raising and location brake system.
  12. Olny except the casting parts the  main other parts use imported materials.

Specifications

Quilting width

64inch

Overall dimensions

2Needle row 3600*1100*1600mm

3Needle row

3800*1200*1650mm



Needle distance

25.4mm

Needle row distance

1-2:3inch 2-3:3inch

1-3:6inch

Net weight

2Row:2300kg

3Row:2600kg

Gross weight

2400kg

2700kg

Running speed

200-500r/m

Output

20-100m/h

Max.thickness

30mm

Max.pattern size

2 Needle Row

(6inch by 6inch )(catercornered distance)

3Needle Row

12inch by 12inch

Voltage

380v 3 phrase

Power

3.5kw

X stroke

8inch (203.2mm )

12inch(304.8mm)

Stitch length

2-6mm adjustable

Application:garments,blankets etc
