Help Center2015 Hat Sale Glass Fiber Covered Copper Flat Wire
Related Products
-
0.15mm 0.61mm 40% Copper Content ECCA WireUS$ 3 - 5MOQ: 500 Kilograms -
200 Degree(HC) Double Coated Enameled Copper Magnet Wire AWG16US$ 7.5 - 10.15MOQ: 500 Kilograms
-
Best Seller Enameled Wire AWG SWG BWG GaugeUS$ 3 - 10.05MOQ: 500 Kilograms
-
Class 200(HC) Enameled Aluminum Flat Wire for Transformer WindingUS$ 3.5 - 5MOQ: 500 Kilograms
-
Enameled Rectangular Copper Magnet Wire Suppliers in ChinaUS$ 7.5 - 9.5MOQ: 300 Kilograms
Glass fiber covered wire
Glass fiber covered wire is a kind of winding wire,first, the ectrical round aluminum rod is extruded or drawed into high quality aluminium conductor,then it is wrapped by the fiberglass,then it is insulated by the varnish and dried.They are mainly used in dry-type transformers,motors and generators coil.
Size:
Rectangular size: a:1.0mm-5.0mm &b:3.0mm-16mm
Round Size: 1-5mm
Materials of Conductor:
Resistivity :Soft copper wire ≤ 0.017241Ω•mm²/m at 20°C
Soft aluminum wire ≤ 0.028000Ω•mm²/m at 20°C
Proof stress Rp0.2:soft < 100 N/ mm2,Semi-hard 100-300 N/ mm²,
The deviation of Proof stress Rp0.2 could be +0-20 N/ mm².
Materials of insulation:
Polymide film and Glass Fibre
Name |
Double Layer Glass Fiber Covered copper Wire |
|||
Model |
GLELB-40/155 |
|||
Diameter |
4mm*6mm |
|||
Standard |
GB/T7672.3-2008 |
|||
Test Item |
Unit |
Technical Requirement |
Test Result |
|
Appearance |
|
Uniform color, no Impact of defects |
Ok |
|
Bare Conductor |
a |
mm |
±0.05 |
3.98 |
b |
mm |
±0.05 |
5.98 |
|
Thickness of insulation film |
mm |
0.32-0.40-0.48 |
0.41 |
|
resistance |
Ω/m |
≤0.02785 |
0.02774 |
|
Elongation |
|
≥17 |
31% |
|
adhesion |
|
10% No cracking |
no cracking |
|
Breakdown Voltage |
V |
560V |
910,850,830,900 |
|
Bending test |
|
a and b winding |
15b, 10a, no crack |
|
package |
|
Meet the export standards |
Ok |
|
Quality Control Result |
|
Ok |
||
