Enameled rectangular copper wire
We supply a=0.8-5.6mm,b=2.0-16mm enameled rectangular copper wire ,class 130,155,180&200 with high output and good price.
Specifications about enameled rectangular copper wire
| Parameter | SMB-130 | SMGB-155 | SMYB-180 | SMYB-200 | SMCB-120 | SMCYB-240 |
| Standars | IEC60317-16 GB/T7095.7 | 60317-16 GB/T7095.3 | 60317-28 GB/T7095.4 | MW 36 60317-29 BS6811 GB/T7095.6 | MW 18 60317-18 GB/T7095.2 | MW 20 60317-47 GB/T7095.5 |
| Thermal Class | 130°C | 155°C | 180°C | 200°C | 120°C | 240°C |
| Enamel Base Coat | Polyester | Modified Polyester | Polyester-Imide | Polyester-Imide | Polyester-formal | Polyimide |
| Enamel Top Coat | Polyester-Imide | |||||
| Range of insulation thickness | IEC60317-0-2 G1,0.06-0.11mm G2/0.12-0.17mm | |||||
| Performance | 1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property | 1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property 5.Higher thermal property | 1.High thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance | 1.Excellent thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance 4.Good resistance to refrigerant and freon | 1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property | 1.Excellent thermal resistance suitable for any electric equipments that are constantly exposed to high working temperature 2.Outstanding mechanical and chemical property 3.Good performance against radiation |
| Application | 1.Dry and oil-immersed 2.Electrical equipment | 1.Dry and oil-immersed 2.Electrical equipment | 1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer | 1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer 4.Automobile coil 5.Train coil | 1.Dry and oil-immersed transformer 2.Electrical equipment | 1.Windings with service temperature up to 220°C 2.Motor and generator for aviation and marine application 3.Nuclear industry 4.Windings requiring high reliability |
| Heat shock | 155°C | 175°C | 200°C | 220°C | 155°C | 300°C |
Services
Why choose us?
Guarantees
1) Factory Direct and on-time shipment.
2) Finest available raw materials,Strict quality control system
3) Customized sizes,OEM are accepted!
4) Goods are sold with rerun or refund guarantee due to quality issue!
Shipping terms
1) We accept terms of delivery EXW, FOB, CFR, CIF, DDU, DDP, etc
2) Sample time: Nearby 3-5days, distance 5-7days.
3) Production time: 10-30days(Depends on the Qty) upon advanced payment received
4) Packing: export standard cartons,drums or customized as per customers’ request
FAQ
[Q] What’s your company 's principle products?
[A] Wire & cable:
Electric wire;Power cable 35kv or below;Overhead bare conductor AAC,ACSR,AAAC,ACAR,AACSR;
Aerial bundle cable; Control cable;Rubber cable& Welding cable
Winding wire/magnet wire
Enameled copper,aluminum,cca wire;Paper covered wireFiberglass covered wire
Galvanized steel wire&strands
[Q] How about your company's production capacity?
[A] Wire& cable:5000km per month
Winding wire/magnet wire:1000 tons per month
Galvanized steel wire&strands:2000 tons per month
[Q] Is there a regular management review of Quality performance Indicators
– Customer satisfaction, on time delivery, Supplier quality, in house scrap ,
in house rejects, Customer returns, etc. ?
[A] Yes, we have for all the ones listed above
[Q] How can I get a sample to check your quality?
[A] After price confirmation, you can require for samples to check our quality.
Sample is free,but the freight charge should be paid.
[Q] what payment terms you can accept?
[A] The payment terms we usually operated is L/C,T/T with deposit and the Payapl,Western Union,
VISA MASTER CARD for small count of order.
