Super Slim P4 Rental LED Display Screen 8 Bit MBI5024 IP43 , LED Video Panel Rental

FOB Price

Negotiable / Kilogram

1 Kilogram(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

TeehoLED

Place of Origin

China

Delivery Time:15-25days
Certification:CE,UL, ROHS, 3C, ISO,FCC

Super Slim P4 Rental LED Display Screen 8 Bit MBI5024 IP43 , LED Video Panel Rental

Quick Detail:

Wide application & short ROI Die casting aluminum cabinet High fresh frequency Light weight and ultra slim design

Description:

1. Ultra thin and slim design

2. HD video with vivid pictures

3. Hanging beam structural design makes it easy and fast for installation

4. locks on both sides of cabinet contribute to uniformity and flatness of two neighboring cabinets.

5. Neat and Hidden Wiring allow the led display more tidy and beautiful.

Applications:

Stage Background

Airport & Station

Television Relay

Information Display

Stadium

Event Show

Specifications:

Part Number	Teeho-P4-16S
Resolution	64(H)×32(V)
Pixel Pitch	4mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	62,500 pixels/
Module Size	256*128mm
Driving IC	MBI5024
Cabinet Size	480mm x 480mm
Driving Method	1/16 Scan, Constant Current
Cabinet Weight	7KG
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	>2,300cd/ ㎡
View Angle	120°/120°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Brightness Adjustment	0～100%
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	850W/ ㎡
Average Power Consumption	280W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
Operating Life	100,000hours
MTBF
