High Resolution BIG P5 Indoor Full Color LED Display For Music Concert , 2000cd /

Name: High Resolution BIG P5 Indoor Full Color LED Display For Music Concert , 2000cd /
Brand: TeehoLED
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Product Details

Brand Name:

TeehoLED

Place of Origin:

China

Delivery Time:15-35days
Certification:CE, 3C , RoHS, ISO,FCC,UL

High Resolution BIG P5 Indoor Full Color LED Display For Music Concert , 2000cd / ㎡

Quick Detail:

1. Super lighter and thinner; 

2. Easy connection and disassembling; 

3. Wide application, good for rental or fixed installation;

4. High resolution and high frequency dynamic image.

Specifications:

Part Number	Teeho-P5-16S
Resolution	32(H)×32(V)
Pixel Pitch	5mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	40,000 pixels/ ㎡
Module Size	160*160mm
Driving IC	MBI5024
Driving Method	1/16 Scan, Constant Current
Cabinet Weight	42kg/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	>2,000cd/ ㎡
View Angle	130°/120°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Brightness Adjustment	0～100%
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	900W/ ㎡
Average Power Consumption	260W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
Operating Life	100,000hours
MTBF	5000hours
Protection Level	～
Out of Control Rate	<0.02%

Description:

1. Cabinet weight is only 7.5 kg, depth 73 mm, decreasing the transportation cost and the intensity of labor.

2. High polym
