Hanging Full Color Outdoor Advertising LED Display P10 10000 Pixels / m

Part Number

TeehoLED-P10

Resolution

16(H)×16(V)

Pixel Pitch

10mm

LED Configuration

1R1G1B -DIP

Pixel Density

10,000 pixels/ m²

Module Size

160×160mm

Cabinet Size

960×960mm, 960×800mm, 800×800mm, etc.

Driving IC

MBI5024

Driving Method

1/4 Scan, Constant Current

Weight

58KG/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

Gap<0.5mm

Optical Ratings

Brightness

7000CD

View Angle

120°/60°

Gray Scale

8bits input, correction with 14bits

Display COLOR

16.7M

Brightness Adjustment

0～100% 10 level

Power Supply

Operation Power

90～260V 50～60Hz

Max. Power Consumption

1000W/ m²

Average Power Consumption

320W/ m²

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60～85Hz

Screen Refresh Frequency

300～1000Hz

Gamma Correction

-5.0～+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Km

Support VGA Mode

1024×768, 1280×1024, 1600×1200, 1920×1280

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-20°～+60°

Operating Humidity

10～95% RH
