Commercial LED Billboard Display For Advertising , LED Large Screen With Pixel Pitch 16mm

Delivery Time:15-20days
Certification:CE,UL, ROHS, 3C, ISO,FCC

Commercial LED Billboard Display For Advertising , LED Large Screen With Pixel Pitch 16mm

Quick Detail:

1. High brightness

2. High gray scale contrast protective

3. High stability

4. Good after sales

Description:

1.Wide application field&short ROI time:Commercial advertising LED display, Stadium perimeter LED display,Mobile trailer LED panel for mobile media,shopping mall LED panel for logo showing,bank&stock exchange LED panel for rates showing,train&bus station,air port,telecommunication LED panel system for information showing and instruction.

2.High Contrast:7000:1,which is a very high level to ensure a vivid image of our LED display screen system.

3. First-class LED chip: Supplied by Ni chia of Japan to ensure the long lifetime and high brightness of our LED screen system.

4.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen’s investment.

5.Long-term Brightness:7000-nit brightness( for outdoor full color) (1200-2700 nits brightness for indoor full color)capacity throughout product lifetime of the LED display.

Applications:

             Outdoor plaza

             Outdoor building

             Stadium

             Shopping mall

             Cross road

             Highway

             Airport

Specifications:

LED Specification

Part Number	TeehoLED- P16
Resolution	16(H)×8(V)
Pixel Pitch	16mm
LED Configuration	1R1G1B -DIP
Pixel Density	3,906 pixels/ ㎡
Module Size	256×128mm
Cabinet Size	1024×768mm, 768×768mm, etc.
Driving IC	MBI5026
Driving Method	Static State, Constant Current
Weight	58KG/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	>8,000cd/ ㎡
View Angle	120°/60°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Brightness Adjustment	0～100% 10 level
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	1200W/ ㎡
Average Power Consumption	350W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_S
