Full Color SMD Indoor Rental LED Display Screen Hire P5 1R1G1B , 40000 Pixels /

Part Number

Teeho-P5－8S

Resolution

32(H)×32(V)

Pixel Pitch

5mm

LED Configuration

1R1G1B 3-IN-1 SMD

Pixel Density

40,000 pixels/ ㎡

Module Size

160mm*160mm

Cabinet size

640x 640x7mm

Driving IC

MBI5024

Driving Method

1/8 Scan, Constant Current

Cabinet Weight

8kg/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

Gap<0.5mm

Optical Ratings

Brightness

1,800cd/ m2

View Angle

150°/150°

Gray Scale

8bits input, correction with 14bits

Display COLOR

16.7M

Brightness Adjustment

0～100%

Power Supply

Operation Power

90～260V 50～60Hz

Max. Power Consumption

850W/ ㎡

Average Power Consumption

280W/ ㎡

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60～85Hz

Screen Refresh Frequency

300～1000Hz

Gamma Correction

-5.0～+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Km

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-30°～+60°

Operating Humidity

10～95%
