TCLL Coil Winding Mechanical Wire Tensioner For Tension Control
- T/T L/C D/P D/A
- 7 days
You May Like
-
Solid Electronic Wire Tensioner For Coil Winding Machine METM
-
DC24V Electronic Wire Tensioner For Wire Breakage Detection METM
-
1.2A Coil Winding Electronic Wire Tensioner For TANAC Winding Machine
-
Solid / Compact Electronic Wire Tensioner With 1.2A , DC24V
-
Solid Coil Winding Electronic Wire Tensioner With 5m / s METSS
-
Compact Electronic Wire Tension With 5m / s
Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
| Model Number | TCL Series |
Product Description
Mechanical Tension Unit Coil winding tensioner coil winder tensioner coil winding tension Unit
TCLL Coil Winding Mechanical Wire Tensioner For Tension Control
|
Place of Origin: |
Dong Guan China |
|
Brand Name: |
KIMCHEN |
|
Model: |
TCL Series |
|
Tension test condition: |
Wire speeding 5m/s refer roundness BOBBIN |
|
Application: |
Winding machine |
|
Function: |
Tension Control |
|
Suit: |
Winding of Big Tension |
|
Product Size: |
240mm*170mm*80mm |
|
Weight: |
1.88KG |
Detailed Product Description:
Mechanical Tensioner(tension device) is one of the vital parts in the coil winding process.It is used to ensure the consistency of the wire tension during the winding process.By using a tensioner,Wire Tension can be adujsted and pre-set to the require value according to the application so as to achieve appropriate winding condition,and to ensure the conformity of each coils technical parameters.
TCL Mechanical Tensioner Specifications:
|
Model |
Applied wire diamiter(mm) |
Tension scope(g) |
|
TCL |
φ0．20—φ0．60 |
200g—2000 |
|
TCLL |
φ0．50—φ1.20 |
1000g—5000 |
|
TC3L |
φ0．70—φ2.00 |
2000g—10000 |
