The rated output power of TP10AS converters is 10W with wide input voltagerange, for both AC input and DC input application. High reliability, precision,large power density, ultra-small size, no external heat sink required, stableoutput voltage and etc, with over current protection, EMI filter circuit, therectifier filter circuit, 2500V isolation voltage, short circuit, overload,internal thermal protection, Widely used in telecommunications, industrialcontrol, instrument, data acquisition, signal control and other electronicsystems.
Part Number |
Input Voltage |
Output |
||
Rated |
Range values |
Voltage（VDC) |
||
(VAC) |
||||
TP10AS220S05 |
220(2:1) |
165-265 |
5 |
|
TP10AS220S09 |
220(2:1) |
165-265 |
9 |
|
TP10AS220S12 |
220(2:1) |
165-265 |
12 |
|
TP10AS220S15 |
220(2:1) |
165-265 |
15 |
|
TP10AS220S24 |
220(2:1) |
165-265 |
24 |
|
TP10AS220D05 |
220(2:1) |
165-265 |
±5 |
|
TP10AS220D12 |
220(2:1) |
165-265 |
±12 |
|
TP10AS220D15 |
220(2:1) |
165-265 |
±15 |
|
TP10AS220D05P05 |
220(2:1) |
165-265 |
+5/+5 |
|
TP10AS220D05P12 |
220(2:1) |
165-265 |
+5/+12 |
|
TP10AS220D05P15 |
220(2:1) |
165-265 |
+5/+15 |
|
TP10AS220D05P24 |
220(2:1) |
165-265 |
+5/+24 |
|
TP10AS220T05D05 |
220(2:1) |
165-265 |
+5/±5 |
|
TP10AS220T05D12 |
220(2:1) |
165-265 |
+5/±12 |
|
TP10AS220T05D15 |
220(2:1) |
165-265 |
+5/±15 |
|
TP10AS220T05D24 |
220(2:1) |
165-265 |
+5/±24 |
|
TP10AS220S05W |
220(4:1) |
85-265 |
5 |
|
TP10AS220S09W |
220(4:1) |
85-265 |
9 |
|
TP10AS220S12W |
220(4:1) |
85-265 |
12 |
|
TP10AS220S15W |
220(4:1) |
85-265 |
15 |
|
TP10AS220S24W |
220(4:1) |
85-265 |
24 |
|
TP10AS220D05W |
220(4:1) |
85-265 |
±5 |
|
TP10AS220D12W |
220(4:1) |
85-265 |
±12 |
|
TP10AS220D15W |
220(4:1) |
85-265 |
±15 |
|
TP10AS220D05P05W |
220(4:1) |
85-265 |
+5/+5 |
|
TP10AS220D05P12W |
220(4:1) |
85-265 |
+5/+12 |
|
TP10AS220D05P15W |
220(4:1) |
85-265 |
+5/+15 |
|
TP10AS220D05P24W |
220(4:1) |
85-265 |
+5/+24 |
|
TP10AS220T05D05W |
220(4:1) |
85-265 |
+5/±5 |
|
TP10AS220T05D12W |
220(4:1) |
85-265 |
+5/±12 |
|
TP10AS220T05D15W |
220(4:1) |
85-265 |
+5/±15 |
|
TP10AS220T05D24W |
220(4:1) |
85-265 |
+5/±24 |
|
