5W 3KVAC Isolation Wide Input AC/DC Converters power supply
TP05AL series is an economical open frame AC/DC switching power supply,The rated output power is 5W
with wide input voltage range, for both AC input and DC input application. High reliability, Low power consumption, safety isolation .Widely used in industrial control and electrical instrumentation, smart home,etc.
Universal input voltage range |
Both for AC and DC input voltage |
Low Ripple &Noise |
High efficiency, high power density, miniature dimensions |
Low power consumption≤50mW
|
Overheat protection ,Over current protection |
International standard Footprint&Pinouts |
Industrial product design |
Operating temperature : -40℃ to 70℃ |
SELECTION GUIDE | ||||||
Part Number |
Input Voltage |
Output |
Efficiency (Typ. ) % |
Ripple &Noise mVp-p ( Typ.) |
||
Voltage （VAC) |
Voltag（VDC) |
Current（A） |
||||
Rated |
Range values |
|||||
TP05AL220S03W |
220(4:1) |
85-305 |
3.3 |
1.00 |
67 |
50 |
TP05AL220S05W |
220(4:1) |
85-305 |
5 |
1.00 |
74 |
50 |
TP05AL220S09W |
220(4:1) |
85-305 |
9 |
0.55 |
76 |
50 |
TP05AL220S12W |
220(4:1) |
85-305 |
12 |
0.42 |
78 |
50 |
TP05AL220S15W |
220(4:1) |
85-305 |
15 |
0.33 |
80 |
50 |
TP05AL220S24W |
220(4:1) |
85-305 |
24 |
0.21 |
82 |
50 |
|
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.
| ||||||
