GD-0165 Vacuum Distillation Apparatus

Chongqing Gold Mech
GD-0165 Vacuum Distillation Apparatus thumbnail-1
GD-0165 Vacuum Distillation Apparatus photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-0165
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-0165

Introduction:

The instrument is designed and made as per the industrial standard of People's Republic of China SH/T0165-92 Standard Test Method for Distillation of High Boiling Point of Petroleum Products at Reduced Pressure. It is suitable to determine the distillation characteristics of high boiling point petroleum products, such as wax oils, lubricating oils, etc.


Features:

1.         This instrument is desktop structure. It is composed of distillation test part and vacuum process part. It can meet requirements of SH/T 0165.

2.         The power of the heating furnace can be adjusted continuously. It equips a cooling device to make the heating furnace cooled down rapidly after determination. It is convenient for next test.

3.         The vacuum pump has good effect. The max residual pressure is 2mmHg.


Specifications:

Power supplyAC 220 V±10%, 50 Hz
Heating powerHeater for distillation flask：1000W，Heater for receiver：350W
Heating power for distillation flask(0~1000)W, adjustable
Temperature range for air bath of receiving flaskAmbient to 100℃, adjustable

Temperature sensor of air bathPt100, RTD
Temperature control mode for air bathDigital temperature controller
Temperature control precisionSet temp. ±1 ℃
Capacity of buffer vessel1000 ml
Max. residual pressure2mmHg
Illumination light in the air bathEnergy saving lamp
Working conditionAmbient temperature: (5~35)℃
Relative humidity: ≤85%
