ISO 9239 Radiant Flooring Panel Test Equipment

FOB Price

US$ 1 - 1 / Bag

1 Bag(Min. Order)

Port Chongqing
Payment TermsT/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	GOLD		Place of Origin	China
Model Number	GD-11785

Product Description

Introduction

Critical Radiant Flux is the main parameters of the fire risk for flooring materials, It reflects the burning and spreading ability of flooring material specimen under external heat radiation conditions, It is an important index of combustion classification for building products. According to ISO9239-1,2 and GB/T 11785-2005 requirements, and Flooring Radiant Panel Tester is measuring the critical radiant of combustion floorcoverings, through the radiation environment of test chamber. It is can also be used to measure the critical radiation of the cellulose insulation floor material.

Standards

• GB/T 11785-2005
• ISO 9239-1: Flooring fire reaction test - Part 1: Combustion performance of flooring materials tested by radiant heat
• ISO 9239-2: Flooring fire reaction test - Part 2: Testing flame spread status under the heat flux is 25kW/m2
• ASTM E 648: Critical Radiant Flux of Floor standard test - covering system uses radiant heat energy
• ASTM E 970: Using a Radiant Heat Energy Source, test insulation floor insulation standard test for Critical Radiant Flux Using a Radiant Heat Energy
• NFPA 253: Standard Test Method for using radiant heat energy, test plates overlay system Critical Radiant Flux
• GB/T 11785-2005

Feature

1, All structural components are made of stainless steel, appearance,and corrosion resistance;
2, The radiation source is a porous ceramic heat radiating plate of 300mmX450mm, and tilted 30 °;
3, The calorimeter is imported from United States , range 50kW/m²;
4, The igniters diameter is 0.7mm, 19/EA, is located at the bottom of the center line of each 60°；
5, The standard plate is made of calcium silicate without coating layer，which is size of 1050X250mm and thickness is 20±1mm ,density is 850 ± 100kg/m³；
6, Small stainless steel auxiliary ignition burner ignited sample.
7, Inlet flow control valve, precise control of propane flow;
8, Equipped with air blower providing air, mixed gas through the venturi mixing gas,

Specifications

Model	GD-11785
Size	1,400(W)500(D)2,200(H)mm
Console Size	600(W)750(D)1600(H)mm
Power	AC 220V, 50/60Hz, 20A
Weight	200kg
Instructions	Available
Exhaust	30~85m2/min
