GD-510Z-1 Automatic Solidifying Point & Pour Point Tester

Chongqing Gold Mech
GD-510Z-1 Automatic Solidifying Point & Pour Point Tester thumbnail-1
GD-510Z-1 Automatic Solidifying Point & Pour Point Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-510Z-1
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-510Z-1

 Introduction:

GD-510Z-1 Automatic Solidifying Point&Pour Point Tester is made as per standards GB/T 510 Standard Test Method for Solidifying Point of Petroleum Products, GB/T3535 Standard Test Method for Pour Point of Petroleum Products. It is a kind of high automatic instrument with advanced design. It is used to determine the solidifying point and pour point of light oils which have good flow ability and low viscosity such as gasoline, light diesel oil and transformer oil. It can be widely used in oil refineries, oil stations and other relevant institutions.


Features:

1.         It adopts SCM as the core control system. Colored touch screen. It can track and display the real-time temperature, and simulate the test status intelligently.

2.         It adopts high accuracy detecting sensor and semiconductor refrigeration technology. The test precision is high.

3.         It uses little mass of oil sample. The test is rapid(5~10 min for one test). The test procedures are completed automatically are injecting the sample. It has good stability and repeatability. The result is reasonable. The test result can be printed after test.

4.         The instrument needs less sample for the determination. The intelligence is high. It can do the test automatically after the sample is added. A micro-printer is equipped.


Specifications:

Applicable oilsThe oils with solidifying point at -60℃~10℃
Precision±1℃ (HWY-15 Low-temperature circulatory water bath is needed when the solidifying point is lower than -50℃ )
Display resolution0.1℃
Maximum cooling depthTemperature difference ≥65℃
Cooling speed15min temperature difference ≥60℃
Requirement for cooling waterPressure: (4.9*10~49*105)Pa
Flow rate: 1.5L/min

Power supplyAC220V±22V，50Hz
Maximum power consumption 250W
Sample dose20ml per time
Working environment(25±10)℃, RH ＜85%
Dimension460*360*470mm
Net weight26Kg
Optional accessoriesLow temperature water bath: GDY-15 Low-temperature circulatory water bath

Product Tags: Pour point tester , Automatic curing point tester , Automatic tester
