GDY-1A Manual Type Oxygen Bomb Calorimeter

Chongqing Gold Mech
GDY-1A Manual Type Oxygen Bomb Calorimeter thumbnail-1
GDY-1A Manual Type Oxygen Bomb Calorimeter photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDY-1A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDY-1A

Introduction:


The instrument is designed and made as per GB/T213 “Test Methods for Calorific Value of Coal”, GB/T384 “Test Methods for Calorific Value of Petroleum Products” and Calibration and Inspection Regulation of People’s Republic of China JJG672 “Oxygen Bomb Calorimeter”, as well as the Company Standard of Shanghai Q/YXYY 10 “XRY-1 Oxygen Bomb Calorimeter”.

The instrument for intelligent data sampling process, computer-controlled, automatic test of combustible material calorific value of automation testing instrument, the instrument can be widely used to determine calorific value of combustible substance such as coal, oil, coke and paraffin, etc. It is the best choice of companies in the field of thermoelectricity, smelt, cement, chemical, and scientific research institutes, and institutions of higher learning.


Features:
•The instrument adopts a high precision temperature sensor and a high performance A/D converter, and uses a SCM to form the temperature collection and transportation system.
•The instrument configuration laptop, composed of a high degree of automation, easy to use, convenient and intelligent data compilation instrument.
•The instrument is fully automated in the testing process, after the sample in place, correct input various parameters automatically without manual intervention to complete each test process; you can print measurement data directly on the A4-format printer configuration after the end of the trial.

Specifications:
Heat capacity(14000 ～ 15000)J/K
Temperature resolution0.001 K
Thermal error≤60J/g
Temperature measurement range10 ℃～35 ℃
Repeatability error≤0.2% (Grade C)
Pressure endured by Oxygen bomb20 MPa
Ambient temperature15 ℃～28 ℃ (room temperature), The temperature fluctuation during each test should be not more than 1 ℃
Storage Temperature data31
Ambient humidityless than 85%
Power supplyAC（220±5%）V，50Hz
Total power consumptionless than 150W
Dimensions600 mm × 460 mm × 430 mm (length × width × height, PC is not included)
Introduction:

1.The instrument is designed and made as per the National Standard of People’s Republic of China GB/T213 “Test Methods for Calorific Value of coal”, GB/T384 “Test Methods for Calorific Value of Petroleum Products” and Calibration Regulation of People’s Republic of China JJG672 “Oxygen Bomb Calorimeter”, as well as Company Standard of Shanghai Q/YXYY 10 “XRY-1 Series Oxygen Bomb Calorimeter”.

2.The heat capacity of the instrument is 14400～14500 J/K, and it is suitable for the determination of water-free oil products (gasoline, jet fuel, diesel oil and fuel oil, etc.) and combustible material such as coal, coke, paraffin wax content determination of calorific value.


Features:

1) The instrument uses a self sealed oxygen bomb, all the structure of the use of stainless steel, the strength is sufficient to withstand the maximum pressure generated by solid combustion (70 ~ 60 ATM), and can withstand the pressure of liquid fuel generated by the greater pressure.

2) The inner tube of the instrument is made by stainless steel sheet, section of pears, put the barrel of water was 3000 grams, water cylinder with electric blender, to ensure that the inner tube water bath temperature uniformity.

3) The instrument of the external water jacket is a double container and experiment when filled with water, through the water jacket mixer to cylinder in uniform temperature, formed to meet the test requirements of the constant temperature environment.


Specifications:


 Note: If the test sample is pulverized coal samples, in order to obtain better test results, we recommend separately of the company's private press cake machine.

Product Tags: Oxygen bomb calorimeter , Manual calorimeter , Manual Type Oxygen Bomb Calorimeter
