Home > Electrical & Electronics > Power Transmission & Transformer > Transformer > GD-11132 Liquid Petroleum Products Hydr℃arbon Tester

GD-11132 Liquid Petroleum Products Hydr℃arbon Tester

Chongqing Gold Mech
GD-11132 Liquid Petroleum Products Hydr℃arbon Tester thumbnail-1
GD-11132 Liquid Petroleum Products Hydr℃arbon Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-11132
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-11132

Introduction:

The instrument is designed and made as per national standard of People’s Republic of China GB/T 11132 Standard test method for hydr℃arbon types in liquid petroleum products by fluorescent indicator adsorption and ASTM D 1319 Standard Test Method for Hydr℃arbon Types in Liquid Petroleum Products by Fluorescent Indicator Adsorption. It is suitable to make the main hydr℃arbon of liquid petroleum products shown on the silica gel adsorption column with fluorescent indicator. Then calculate it’s volume percentage. This will be regarded as the quality measurement index of engine fuel, aviation fuel and other fuel oils.

The instrument is a kind of professional instrument determining percentage of aromatic hydr℃arbon, olefin and saturated hydr℃arbon in petroleum fraction.


Features:

1. Vertical type and unit-body design. No need to install.
2. This instrument is composed of air circuit system, vibration unit, scale indicator, illumination and UV-light detecting component.
3. Two pieces of imported precise glass tube adsorption column. It is convenient to operation.
4. Equipped with a adsorption column cleaning unit. Solve the problem for cleaning the adsorption column.


Specifications:

Power supplyAC220V±5%，50Hz
Pressure regulating range of reducing valve(0~400)kPa
Electric agitatorIndependently controlled for each way
Ultraviolet light source pipe1220mm in length，wavelength is 365mm±5nm
 Illuminating lamp1220mm in length，power is 40W
Air supply Nitrogen cylinder (or air compressor，compressed air bottle)
Ambient temperature(5~35)℃
Relative humidity ≤85%
Dimension350mm*400mm*1770mm
Maximum power consumption600W

Product Tags: Water ℃ arbon tester , Oil tester , Liquid Petroleum Products Hydr℃arbon Tester
