Detailed Product Description
| Sheath Material: | PVC | Range Of Application: | Lvds |
| Type: | Insulated | Conductor Material: | Copper |
| Conductor Type: | Solid | Insulation Material: | PVC |
| Material Shape: | Twisted Pair | Color: | Black / Beige / OEM |
| Length: | 3.0meters | Connector: | 3m Solder Type Mold PVC |
| Max Length: | 15meters 40MHz |
MDR/SDR to SDR/MDR 26 Pin Camera Link Cables 11 pair Twisted Cable 28AWG and 30AWG
Description:
1,Connector Type
Camera Link cables are available in a range of connector options.
SDR (Shrunk Delta Ribbon Cables)
26-Pin
Smaller than MDR
Sometimes Called Mini Camera Link
Male External
Molded Backshell
MDR (Mini D Ribbon Cables )
26-Pin
Male Molded Backshell
Male Latched Metal Backshell
Female Internal or External
Female Molded Backshell
Female Thumbscrew or Standoff
2, Meets Automated Imaging Association(AIA)Camera Link Standard.
3, Power over Camera Link (PoCL) Cable Assemblies carry power
4, Connects between Mini-Camera Link style (SDR) I/O ports on PoCL Cameras and Camera Link style (MDR) ports on PoCL,compatiable with Non PoCL Camera Link Cable MDR To SDR / HDR 26Pin.
5, All our Camera Link cable assemblies meet High Flex specification. Lifetime test passing over 3 million cycles and progressing.Flex test term: Locomotive track / Flex Rdius / Flex Speed
6, Ultra low noise Mini Camera Link Cable Assemblies: Skew (within pair): 35 ps/meter maximum
Skew (Channel skew per chipset): 50 ps/meter maximum
7, PoCL and Non PoCL type available
8, Straight, Up and Down Directions for SDR mini connectors
9, 1M,2M,3M,4M,5M,6M,7M,8M,9M,10M with stock for short time delivery,max length 15meters at frequency 40Mhz.
10, RoHS and UL approval
11, Custom Camera Link Capabilities:
can incorporate additional requirements to your Camera-Link cable assemblies including ferrites, labels, bar-codes, and custom packaging.
Add your logo to Camera Link Cables!
MDR male and female molded backshells accept custom logos.
SDR Multi-Leg Custom Assembly
On-site engineering and production allows us to custom build your Camera Link cables and oversee the manufacturing process within strict conformance to the quality of USA-made product.
Camera Link to SCSI & Other Hybrids
MDR & SDR to HD68, VHD68, VHDCI
MDR & SDR to D-Sub
MDR & SDR to Military D38999 Connectors
Overmolding
Octopus, "Y" Cable, & Hybrid Molds
Company Logos
Custom Specs and Services
Custom Connector Configurations
Custom Pinouts
Custom BOMs
Custom Labeling
Custom Packaging
Application:
1, Machine Vision Industrial Cameras,Image Frame Grabbers. Vision Components.
2, Factory Automation Equipment / Device.
3, Industrial Control.
4, Digital Camera CCD CMOS Cameras.
5, Use in other LVDS signaling applications is also possible.
