This oil purification plant is special for purifying all kinds of lubricating oil such as the Engine oil, hydraulic oil, mechanical oil, coolant oil, gear oil, heat treatment oil and so on. According to the lubricating oil’s nature, this machine can rapidly remove water, gas, particulate matters and impurities from lubrication oil, so guarantee lubricating system of machine to work properly and prolong lifetime of machine.
Features
1. Strong capability of breaking emulsification.
2. The combination of coalescing separation and vacuum dewatering.
3. More Deeply and precisely FH rectangle filtering system. The oil will reach to the new oil’s nature when it was purified.
4. Zhongneng’s unique technology with H.P.M high molecule absorption material.
Advantages
This oil purification can fast degas, dewater, and remove the impurity and the volatile matter (for example ethyl alcohol, gasoline, ammonia and so on). Enhances the oil quality, restores the lubricating oil viscosity, augments the flash point and improves the operational performance. Guaranteed the hydraulic system and the dynamic system, the lubrication system normal operation, so the machine is suit for many lines, such as the mine, metallurgy, electric power, transportation, manufactures and so on.
Technical Parameter
Item |
Unit |
TYA-10 |
TYA -20 |
TYA -30 |
TYA -50 |
TYA -100 |
TYA -150 |
TYA -200 |
TYA -300 |
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
Vacuum degree |
Mpa |
-0.06 ~ -0.095 |
|||||||
Working pressure |
Mpa |
≤0.4 |
|||||||
Temperature degree |
℃ |
0~100 |
|||||||
Last working |
H |
150 |
|||||||
Working noise |
DB (A) |
≤75 |
≤75 |
≤75 |
≤78 |
≤78 |
≤78 |
≤80 |
≤82 |
Electric heating power |
KW |
36 |
40 |
45 |
72 |
80 |
90 |
120 |
135 |
Total electric power |
KW |
38 |
42 |
47 |
75 |
87 |
101 |
135 |
147 |
Inlet (outlet) caliber |
mm |
Ф25 |
Ф25 |
Ф25 |
Ф32 |
Ф42 |
Ф50 |
Ф50 |
Ф60 |
Size |
mm |
1500x1000x 1600 |
1500x1050x 1600 |
1500x1050x1650 |
1600x1150x1700 |
1750x1150x1750 |
1900x1600x1950 |
1950x1600x1950 |
2100x1600x2000 |
Weight |
Kg |
350 |
380 |
400 |
450 |
550 |
650 |
700 |
750 |
Viscosity index |
mm2/S |
GB443-89 |
|||||||
Flash point（open cup） |
℃ |
GB443-89 |
|||||||
Moisture |
% |
No trace water (GB/T260) |
|||||||
Mechanism impurities |
% |
0.05~0.005(GB/T511) |
|||||||
