Help Center2013 Low Investment Small Scale Magnetic Separator for Iron Sand Processing
Related Products
-
Large Capacity Magnetic Separator for Iron Ore SeparationUS$ 15,000 - 15,500MOQ: 1 Set -
Largest Magnetic Separator for Iron Sand Processing PlantUS$ 33,000 - 33,500MOQ: 1 Set
-
Jumbo China Brand Robust DPX Series Hammer CrusherNegotiableMOQ: 1 Set
-
2013 PYB1200 Spring Cone Crusher for Quarry ProjectUS$ 60,000 - 61,000MOQ: 1 Set
-
Best Price of Small Hammer Mill for Soft Rock CrushingNegotiableMOQ: 1 Set
Specifications
1. ISO9001:20002. Long service life
3. wide application in iron ores
4. low running cost and low maintenance cost
The Magnetic Separator is suitable for wet magnetic separation of materials such as
magnetite, calcined ore, etc. and it can remove the iron in the coal, nonmetal and construction industries.
The magnetic system is made from high quality ferrite magnetic materials and /or rare earth magnet steel.
On the shell surface, the magnet intensity is 100600mt.
The wet type permanent magnet cylindrical separator is commonly used for iron ore separation.
It is suitable for separating materials with high magnetism. In recent years, it has been used as concentrating equipment in place of magnetic dewatering cell.
Model: CTB7518
Dia. of tube body: 750 mm
Length of tube body: 1800 mm
Rotation speed of tube body: 35 rpm
Magnetic induction: 1200-1500
Feed size: 0.4-0 mm
Capacity: 25-35 t/h
Electrical motor power: 3 kw
Dimensions (L*W*H) (mm): 2880*1970*1500 mm
Weight: 2.1 t
