2013 PYB1200 Spring Cone Crusher for Quarry Project
US$ 60,000 - 61,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cone Crusher
Application:
Metallurgy, construction, road building, chemical & silicate industry
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Price of Small Hammer Mill for Soft Rock CrushingNegotiableMOQ: 1 Set -
Professional & Best Price Roller Crusher in 2013NegotiableMOQ: 1 Set
-
Spring Type Classical Cone Crusher PYB-1200 for Hard Material CrushingUS$ 60,000 - 61,000MOQ: 1 Set
-
China 3 Feet Small Hydraulic Cone Crusher for Hard Stone MiningNegotiableMOQ: 1 Set
-
Top Quality Mineral Stone Screening Machine for SeparatingUS$ 9,999 - 10,000MOQ: 1 Set
Condition
New
Type
Cone Crusher
Application
Metallurgy, construction, road building, chemical & silicate industry
Motor Type
AC Motor
Power(W)
110
Capacity(t/h)
110-200 t/h
Place of Origin
Henan, China
Brand Name
UNIQUE
Model Number
PYB1200
Dimension(L*W*H)
4152*2300*2980mm
Weight
24.7t
Certification
ISO
Warranty
15 months
Specifications
suitable for hard stone crushing with large capacity and high crushing ratio| Model | Crushing cone dia. (mm) | Max. feed size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Dimensions (mm) |
| PYB1200 | 1200 | 145 | 20-50 | 110-200 | 110 | 24.7 | 4152*2300*2980 |
Cone Crusher is one of the main types of crushers in a mine site or ore processing plant. Cone crushers are designated in size either by the gape and mantle diameter or by the size of the receiving opening.
Cone crushers can be used for primary or secondary crushing. The crushing action is caused by the closing of the gap between the mantle line (movable) mounted on the central vertical spindle and the concave liners (fixed) mounted on the main frame of the crusher. The gap is opened and closed by an eccentric on the bottom of the spindle that causes the central vertical spindle to gyrate. The vertical spindle is free to rotate around its own axis.
