ADSS Optical Cable, Nonmetallic Optical Fiber Cable GYFTC8Y

Name: ADSS Optical Cable, Nonmetallic Optical Fiber Cable GYFTC8Y
Brand: TOTAL
SKU: 143613426
Availability: InStock

Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

TOTAL

Model Number:

GYFTC

Shanghai Total Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name TOTAL

Model Number GYFTC

Type Cat 6a

Product Description

·Feature & Benefits
Long-distance communication, local trunk line, CATV & computer networks system.
·Application
Low dispersion and attenuation.
Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental characteristics.
Anti-electromagnetism ability.
Small cable diameter, light cable weight, self-supporting, easily to install.
·Main Technical Parameters
Fiber	Cable dimension(mm)	Cable net weight	Min. bending radius		Min. tensile strength		Min. crush pressure
number		(Kg/km)	(mm)		(N)		(N/100mm)
			Static state	Dynamic state	Short term	Long term	Short term	Long term
30 and below	10.0*19.6	174	100	200	6000	2000	1000	300
32~36	10.6*20.2	184	110	220	6000	2000	1000	300
38~60	11.3*20.9	196	120	240	6000	2000	1000	300
62~72	12.1*21.7	212	130	260	6000	2000	1000	300
74~84	12.9*22.5	226	130	260	6000	2000	1000	300
86~96	13.7*23.3	242	140	280	6000	2000	1000	300
98~108	14.5*24.1	260	150	300	6000	2000	1000	300
110~120	15.3*24.9	278	160	320	6000	2000	1000	300
122~132	16.1*25.7	298	170	340	6000	2000	1000	300
134~144	16.9*26.5	318	170	340	6000	2000	1000	300
Messenger wire			Φ1.2mm*7 Steel wire strand
Web			Height * Width: 3.0 * 2.5mm
Operating temperature			-40~+60℃
