N Female to Right Angle Mmcx Pigtail Coaxial Cable With 179 Cable 8cm

Name: N Female to Right Angle Mmcx Pigtail Coaxial Cable With 179 Cable 8cm
Brand: custom
SKU: 115379497
Availability: InStock

US$ 0.67 - 1.27 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

custom

Model Number:

RG 179 cable

Shenzhen Yetnorson Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name custom

Model Number RG 179 cable

Number of Conductors 1

N Female to right angle mmcx pigtail coaxial cable with 179 cable 8cm

Application :

Coaxial cables are used in high frequency transmission,especially for transmiters and receivers,

computers,radio and TV transmissions.The varied mechanical,thermal and electronic properties

of Coaxial cables mean that they can be used up into the GHz levels,as pes cable type

Product Description

SPEC of N Female to right angle mmcx			Structure of product N Female to right angle mmcx Coaxial pogtail cable
Connector Technical Characteristics	Frequency Range(MHZ)		174~862

	V.S.W.R		≤1.50+0.02f
	Impedance (Ω)		50Ω
	Insertion Loss		0.6DB
	Plating		gold plated
	KV		50±2
	Insulator		PTFE
RG Flexible Cables Technical Characteristics	Cable Type		179
	Center Conductor		0.2 /Sliver Plated)
	Insulation Dimensions		Ø 0.81±0.1mm PTFE
	Screen Dimensions		Ø0.81 Sliver Plated
	Jacket Dimensions		Ø0.81
	Nominal Impedance		50Ω
Environment Specifications	Operation temperature		-55~+150°C
	Operation Relative humidity		55%~75%
Testing voltage of spark			2000V
Testing voltage			2000V
Attenuation(Typical)(dB/m)		470MHz	0.31dB
		665 MHz	0.52dB
		712MHz	059dB
		800 MHz	0.61dB
		862 MHz	0.65dB
