Crushing and dividing integrated machine for laboratory sample preparation

Specifications

Jaw crusher&divider machine
-Sieving,crushing,dividing function
-Cutter-chute divider
-Lab use jaw crusher
-13mm, 6mm screen



Crushing and dividing integrated machine for laboratory sample preparation







Typical Applications:

This crushing and dividing integrated machine is used for making ≤100mm coal, coke or medium-hard material samples to the size between 6-38mm(adjustable) and the weight of 1/2-1/16 of feeding material for component analysis by impact crushing, mixing, dividing.The machine with automatic feeding material device that decreases the labor intensity.





The unit is especially suitable for sample preparation work in the laboratory of industrials of coal, electricity, nonferrous metal, metallurgy, chemic, environment-friendly department, scientific research and so on.



Advantages:

1. Automatic finish the crushing, mixing and dividing, wihic insure the precision of samples and avoid the manual error;



2. Automatic cutter-chute division system makes sure the representation of sample.



3. All moving parts has the safeguards which meets the requirements of work safety;



4. Full-sealed design and equipped with dust outlet which meet the requirements of environment protection. And the door makes daily maintenance more convenient;



5. It can work normally on the flat ground without fixing any base.





 Technical Parameter of Jaw Crusher With Divider

Model No.	GM/EPS-1/8	GM/EPS-A	GM/EPS-AX
Feeding size (mm)	≤45mm	≤100mm	≤200mm
Discharging size(mm)	3-6mm    (Adjustable)	6-38mm       (adjustable)	10-40 (adjustable)
Division ratio (adjustable)	(About)1:8	(About)1:2,1:4,1:8,1:16(Adjustable)	(About)1:2,1:4,1:8,1:16(Adjustable)
Handling capacity (kg/h)	200-500	500-1200	1000-2000
Moisture	≤11%	≤11%	≤11%
Mesh size of shaking sieve(mm)	13 or 6	13 or 6	13 or 6
Motor Power (kw)	1.5	4	7.5
Dimension (mm)	640×1150×1300	790x1060x1490	800x670x1600
Working power supply(v)	380	380	380
Total weight(kg)	300	600	1000
Automatical feeding material device





Packaging way: plywood case, customize case based on jaw crusher size;

Shipping way: by sea, by air as requested.





 -Within 24hours prompt reply;

-15-30day on time delivery;

-Quality assurance, the disc mill has 12months warranty time;

-High qualified engineer and sales provide good service for each customer;

-Experienced cooperation forwarder satisfies customer’s various shipping arrangement.



The automatical jaw crusher with divider supplier-Guangming is a leading laboratory sample preparation equipment manufacturer in China,and has 30years experience in the industry,laboratory jaw crusher, pulverizer, sieve shaker, rotary sample divider, calorimeter, sulphur tester are the featured products, these products are hot sell in worldwide and receive good feedback from customers, SGS is one of our customers.

Depending on rich experience and advanced technology, Guangming develop many patented products, such as the first set coal integrated sample preparation system, the first unmanned coal sample preparation system etc, and has our own intellectual-property rights.We also participated in national standards establishment, Our general manager is technical member of national standard technical committee.



We insist on independent innovation, to achieve the goal of building world brand in the sample preparation industry, Guangming units a number of high qualified engineer and talented managing persons to provide customers advanced product and good service.
