SM100 Portable Water Well Drilling Rig for Irrigation
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Core Drilling Rig
Power Type
Diesel
Place of Origin
Fujian, China
Brand Name
DSL
Model Number
SM 100
Usage
Water Well
Specifications
SM 100 Water well drilling rig1 water well drill
2 water drilling rig machine
Water well drilling rig
item name: portable core drilling rig for geological, diamond core drilling rig, hydraulic core drilling rig, core drilling rig for site invstigation, trailer mounted core drilling rig, core drilling machine,
Railway, electricity, transportation, bridges, dam, etc building engineering geology survey, geological core drilling, physical investigation.
Small hole blasting hole grouting and drilling,small wells drilling. Small water well drilling
alleviate labor intensity was workers.
| MODEL | XY-100 |
| 1. Unity machine parameter | |
| Drilling depth | 100m |
| Maximum open hole caliber | 300mm |
| End hole caliber | 75mm |
| Drill rod caliber | 50mm |
| Drilling angle | 90~75 |
| Drill weight (Not including power) | 520kg |
| Unity machine dimensions | 2*0.9*1.4m |
| 2. Spindle | |
| Spindle speed | 142.285.570r/min |
| Spindle stroke | 450mm |
| 3. Hoist | |
| Max.single line hoisting capacity | 1600kg |
| Tightrope caliber | 11mm |
| Tightrope cubic measure | 27m |
| Hug floodgate caliber | 230mm |
| Hug floodgate belt width | 50mm |
| 4. Mud pump | |
| Type | Horizontal single urn twin-action |
| Displacement | 95/77L/min |
| Maximum pressure | 1.2Mpa |
| Work pressure | 0.7Mpa |
| Water inlit caliber | 42mm |
| Water to exit caliber | 32mm |
| 5. Power | |
| Diesel engine | 18HP |
| Speedlimit | 2000r/min |
| Electric motor | 11kw |
| Speedlimit | 1460r/min |
| MODEL | XY-150 |
| 1. Unity machine parameter | |
| Drilling depth | 150m |
| Maximum open hole caliber | 400mm |
| End hole caliber | 75mm |
| Drill rod caliber | 50mm |
| Drilling angle | 90~75 |
| Drill weight (Not including power) | 760kg |
| Unity machine dimensions | 2*1*1.4m |
| 2. Spindle | |
| Spindle speed | 140.295.470.790.1010r/min |
| Spindle stroke | 450mm |
| 3. Hoist | |
| Max.single line hoisting capacity | 1600kg |
| Tightrope caliber | 12mm |
| Tightrope cubic measure | 35mm |
| Hug floodgate caliber | 245mm |
| Hug floodgate belt width | 70mm |
| 4. Mud pump | |
| Type | Horizontal single urn twin-action |
| Displacement | 95/77L/min |
| Maximum pressure | 1.2Mpa |
| Work pressure | 0.7Mpa |
| Water inlit caliber | 50mm |
| Water to exit caliber | 42mm |
| 5. Power | |
| Diesel engine | 18HP |
| Speedlimit | 2200r/min |
| Electric motor | 11kw |
| Speedlimit | 1460r/min |
| MODEL | XY-180 |
| 1. Unity machine parameter | |
| Drilling depth | 180m |
| Maximum open hole caliber | 400mm |
| End hole caliber | 75mm |
| Drill rod caliber | 50mm |
| Drilling angle | 90~75 |
| Drill weight (Not including power) | 760kg |
| Unity machine dimensions | 2*1*1.60m |
| 2. Spindle | |
| Spindle speed | 71.142.310.620r/min |
| Spindle stroke | 450mm |
| 3. Hoist | |
| Max.single line hoisting capacity | 2008kg |
| Reel lifting speed | 17,35,75,160rm/s |
| Tightrope caliber | 13mm |
| Tightrope cubic measure | 35mm |
| Hug follgate belt width | 70mm |
| 4. Mud pump | |
| Type | Horizontal single urn twin-action |
| Displacement | 180L/min |
| Maximum pressure | 1.5Mpa |
| Work pressure | 0.7Mpa |
| Water inlit caliber | 50mm |
| Water to exit caliber | 45mm |
| 5. Power | |
| Dieselengine | 22HP |
| Speedlimit | 2200r/min |
| Electric motor | 15kw |
| Speedlimit | 1460r/min |
| MODEL | XY-200 |
| 1. Unity machine parameter | |
| Drilling depth | 200m |
| Maximum open hole caliber | 400mm |
| End hole caliber | 75mm |
| Drill rod caliber | 50mm |
| Drilling angle | 90~75 |
| Drill weight (Not including power) | 760kg |
| Unity machine dimensions | 2.75*0.95*1.6m |
| Distance betweent drill and hole | 450mm |
| 2. Spindle | |
| Spindle speed | 71,142,310,620r/min |
| Spindle stroke | 450mm |
| 3. Hoist | |
| Max.single line hoisting capacity | 2008kg |
| Reel lifting speed | 17,35,75,160rm/s |
| Tightrope caliber | 13mm |
| Tightrope cubic measure | 35mm |
| Hug follgate belt width | 70mm |
| 4. Mud pump | |
| Type | Horizontal single urn twin-action |
| Displacement | 180L/min |
| Maximum pressure | 1.5Mpa |
| Work pressure | 0.7Mpa |
| Water inlit caliber | 50mm |
| Water to exit caliber | 45mm |
| 5. Power | |
| Dieselengine | 22HP |
| Speedlimit | 2200r/min |
| Electric motor | 15KW |
| Speedlimit | 1460r/min |
