prefabricated steel construction building light steel building
Steel structure design common norms are as follows:
"Steel Design Code" (GB50017-2003)
"Cold-formed steel structure technical specifications" (GB50018-2002)
"Construction Quality Acceptance of Steel" (GB50205-2001)
"Technical Specification for welded steel structure" (JGJ81-2002, J218-2002)
"Technical Specification for Steel Structures of Tall Buildings" (JGJ99-9)
Commonly used steel grades and performance of steel:
Carbon structural steel: Q195, Q215, Q235, Q255, Q275, etc.
High-strength low-alloy structural steel
Quality carbon structural steel and alloy structural steel
Special purpose steel
Specs | Length | unlimited |
span | single span, multi span, economical span 25m | |
Eave Height | up to 50m, common height 4m ~10m | |
Color | According to customers | |
Size | MOQ is 1000m2, width *length *eave height |
Main components | Base | Cement and steel foundation bolts |
Main frame | H beam&column | |
Material | Q235B,Q345B or others as buyers' requests. | |
Purlin | C or z purlin: size from C120~C320, Z100~Z20 | |
Bracing | X-type or other type bracing made from angle steel, round pipe, etc | |
Bolt | common bolt , High-strength bolt, shearing bolt , bracket bolt | |
Roof &wall | sandwich panel like EPS,Rock wool,PU, corrugated steel sheet with fiber glass wool | |
Door | Rolled up door or Sliding door(sandwich panel) | |
Window | Plastic steel or Aluminum alloy window | |
Surface | Two lays of Anti-rust Painting or Hot Dip Galvanized | |
Sheet | 0.4m, 0.5mm or 0.6mm galvanized sheet | |
Accessories | Semi-transparent skylight belts,Ventilators, Down pipe, Galvanized gutter, etc |
Advantages | 1.Lower cost but beautiful outlook. 2.High safety performance. 3.easy to assemble and dismantle. 4.manufacture under complete quality control system-ISO9001 5.installation with instruction of experienced engineers 6.Non-pollution. |
Application | 1. workshop,warehouse,plant 2. Steel web frame structure 3. Steel H-column and steel H-beam 4. Portal frame products 5. High rise building project 6. Others steel structure buildings |
Packaging | Main steel frame without packing load in 40'OT, Roof and wall panel load in 40'HQ! |
Payment | L/C or by T/T(30% prepaid as deposit, the balance 70% before shipment) |
Drawing | According to the drawings or according to the customer’s requirements. |
Design Parameters | If you need us to design for you, please provide the following parameters: 1)length, width, height, eave height, roof pitch, etc 2)wind load, snow load, raining condition, aseismatic requirements, etc 4)Demands for doors and windows 5)Other information if needed. |
Company Information
Xuecheng Steel Structure is specialist for kinds of steel structure buildings and main frames, secondary frames and members, we have 7 year's experience in steel structure products, and our products have been successfully exported to Australia,North America, South America, Eastern Europe, Southeast Asia, Africa, etc
FAQ
1. Common type of the industrial building?
Reply: Portal frame is the usual type in the industrial workshop and warehouse shed. Other types also could be designed and manufacturer as per clients’ request.
2. What’s the quality grade of the steel structure components?
Reply: Q345 is used for main steel structure, Q235 is used for secondary steel structure.
3. How about the delivery time?
Reply: Usually,within 45-60 days after the order confirmed, also depends on the fabrication quantity.
4. How about the derust grade?
Reply: Ball blasting Sa2.5 on main steel structure; manual derust St2.0 on secondary steel structure.
5. What kind panel used for the roof and wall?
Reply: Color corrugated steel sheet and sandwich panel could be used. Sandwich panel performs well on the heat insulation,sound insulation.Common sandwich materials are EPS, glass wool and PU.
6. How to install it?
Reply: We will furnish you the detailed construction drawing and the construction manual which could help you to erect and install the building step by step. We also could send the engineer to help you if needed.
