Specifications
1.Quality 24 AWG stranded (flexible) cable2.High grade 50u gold plated RJ45 connector
Category 6a UTP Patchcords
Category 6a Unshielded Twisted Pair (UTP) patchcords conform to class EA standards. Our patchcords are made to the highest standards using only quality stranded cable, giving them the best in flexibility, plus top grade 50μ gold plated RJ45 connector plugs for high quality connections. This combination makes for outstanding performance and reduced degradation. All patchcords are produced with an injection moulded boot with an easy depression latch cover. Available across 8 colours, 6 standard lengths and in PVC or LSZH jacket varieties. For best performance we recommend these as part of a full Enyoo Category 6a system.
Features
Quality 24 AWG stranded (flexible) cable
High grade 50μ gold plated RJ45 connector
Injection moulded boot for improved strain relief
Soft latch-cover design for easy depression
Applications
Supports Category 6a, 6 and 5e networks running up to 500 MHz applications
Backwards compatible with Category 6a distribution system
Conformance
Category 6a
ISO/IEC 11801 : 2002
ANSI/EIA/TIA 568B.2.1 : 2002
RoHS
Technical Specification
| Construction | value | |
| Conductors | AWG | 24 |
| Size mm | 7/0.20 +/- 0.008 | |
| Material | Bare Copper | |
| Insulators | Diameter mm | 0.98+/-0.05 |
| Material | Polyolefin | |
| Jacket | External O.D. | 6.0 +/- 0.20 |
| Thickness mm | 0.5 | |
| Material | PVC | |
