Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > Network Cable Utp Cat5e 4pr 24awg
Network Cable Utp Cat5e 4pr 24awg
US$ 16 - 19
MOQ: 1 Roll
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
enyoo
Model Number:
utp cate5e
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lan Cable Cat 5e UTP Patch Cord,Cu,CCA,CCSUS$ 0.1 - 5MOQ: 100 Pieces -
Cat 5e Patch Cord,utp Cu,CCA,CCSUS$ 0.1 - 5MOQ: 100 Pieces
-
Cat6 FTP Cable/Lan Cable/Network CableUS$ 10 - 50MOQ: 100 Boxes
-
Cat 5e/cat6 Patch Cord,utp Cu,CCA,CCSUS$ 0.1 - 5MOQ: 100 Pieces
-
Cat6 Patchcords,utp Cu,CCA,CCSUS$ 0.1 - 5MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
enyoo
Model Number
utp cate5e
Type
Cat 5e
Number of Conductors
8
Specifications
work cablework cable 24 AWG
work cable PVC, LSZH and PE
4.print meter marks in cable
5.rohs
network cable cat 5e UTP Cable
Category 5e Unshielded Twisted Pair (UTP) 100 Ohm cable is produced using a 4 x 2 x 24 AWG copper wire structure to a Class D standard. It supports the gigabit Ethernet protocol for horizontal and backbone installations.
Features :
24 AWG conductor – solid bare copper cable
PVC, LSZH and PE options
Supplied in 305m box
Printed metre marks
Applications :
Supports Category 5e (Class D) networks running up to 100 MHz applications
Horizontal and backbone installations
10 Base T (IEEE 802.3)
100 Base T (IEEE 802.3U)
ATM 155
100 VG any LAN (IEEE 802.12
Conformance :
Category 5e
ANSI/EIA/TIA 568B.2 : 2002
ISO/IEC 11801 : 2002
RoHS ETL/UL approved
Technical Specification
| construction | value | |
| Conductors | AWG | 24 |
| Size mm | 0.50 | |
| Material | Bare Copper | |
| Insulators | Diameter mm | 0.88+/-0.02 |
| Material | HDPE | |
| Jacket | External O.D. | 5.0 +/- 0.3 |
| Thickness mm | 0.50 +/- 0.05 | |
| Material | PVC / LSZH / PE | |
Ordering Information :
| Description | Part No |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable PVC 305m Box - Grey | UTP5E305PVC |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable LSZH 305m Box - Violet | UTP5E305LSZH |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable External PE - 305m box | UTP5E305EXT |
