Specifications
1.Quality 26 AWG stranded (flexible) cable2.High grade 50u gold plated RJ45 connector
Category 6 FTP Patchcords
Category 6 Foiled Twisted Pair (FTP) patchcords conform to Class E standards. Our patchcords are made to the highest standards, using only quality stranded cable, giving you the best in flexibility and top grade 50μ gold plated RJ45 connector plugs. This combination makes for outstanding performance and reduced degradation. Aluminium tape is used to shield all 4 pairs; this gives a screened protection against external interference such as EMI. All patchcords are produced with a injection moulded boot with easy depression latch cover. Available across 8 colours, 6 standard lengths and in PVC or LSZH jacket varieties. For best performance we recommend you use these as part of a full Enyoo Category 6 system.
Features
Quality 26 AWG stranded (flexible) cable
High grade 50μ gold plated RJ45 connector
Injection moulded boot for improved strain relief
Soft latch-cover design for easy depression
Applications
Supports Category 6 (Class E) networks running up to 250 MHz applications
Ideal for environments where heavy external interference can disrupt sugnal such as EMI
Backwards compatible with Category 5e distribution system
Conformance
Category 6
ISO/IEC 11801 : 2002
ANSI/EIA/TIA 568B.2.1 : 2002
RoHS
Technical Specification
| Construction | value | |
| Conductors | AWG | 26 |
| Size mm | 0.915 +/- 0.008 | |
| Material | Bare Copper | |
| Insulators | Diameter mm | 0.97+/-0.05 |
| Material | Polyolefin | |
| Jacket | External O.D. | 6.0 +/- 0.20 |
| Thickness mm | 0.5 | |
| Material | PVC or LSZH | |
| Tape | Material | Aluminium Mylar |
| Coverage (%) | 125 | |
