Micro-controlled automatic brake shoe slack adjuster test bench

Specifications

The tester can detect and analyze parameters according to railway standards,then memorize,manage,print them automatically.

Technical parameter:

Experiment range: ST serials automatic brake shoe slack adjuster

Experiment method: automatically test and controlled by microcomputer

Experiment speed: ≤8 min per unit

Measurement uncertainty0.2mm

Output Modeman-machine interaction,printout,autosave

Working temperature: -10~+55, relative humidity ≤90%

Electric power: AC220V±20V/50HZ,0.5Kw, earth resistance:≤4

Pneumatic power: ≥0.4MPa

Outline dimensions: 5000mm×560mm×1200 mm(length×width×height)

Weight: 2.5T

Functions:

1            It uses industrial computer as the core to analyze the data, and then according to the result accomplish the test by controlling the circuit part and the part.

2            It is automatically controlled by microcomputer which operates safely and stably.

3            It could connect and share accurate test data with the information management systems in workshop.

4            The design of intelligent software system can alarm various anomalies promptly
