GAOFU Full-closed type Vibratory Bowl Feeder
- 100 Set / Sets per Month
- Tianjin / Shanghai / Qingdao
- T/T
Product Details
Condition: | New | Capacity(t/h): | 100-500t/h | Place of Origin: | Henan, China |
Brand Name: | GAOFU | Model Number: | ZG-516-Q235ACarbon steel | Application: | Ore, stone, rock, coal, sand, construction material, etc |
Warranty: | One year |
Packaging Details
make sure meet the export standard ,according to the size of different .
Product Description
Electric Vibrating Feeder
1. Brief Introduction of vibratory bowel feeder :
*.Widely used as crushing and screening joint equipment in the cement plant for continuously and evenly feeding cement materials
*.In the cement production line, the even and continuous feeding helps avoid the feeding hole blocking of cement crusher
2. Features of vibratory bowel feeder:
*.Double screening and embodies the functions of dirt removing, screening and feeding
*.It is characterized by even feeding, excellent continuity and adjustable vibrating force
*.Smooth operation, great feeding capacity and high efficiency
*.Eccentric block is the vibration source which features smooth operation, low noise, little electricity consumption, excellent adjustability and causes no material clashing
3.Specification of vibratory bowel feeder:
Type | GZD850 X3000 | GZD960 x3600 | GZD1100 x3800 | GZD1200 2400x | GZD1300 X4900 | GZD1500 X6000 |
Max.Feeding Size | 400 | 500-580 | 580 | 580 | 650 | 800 |
Handling Capacity (t/h) | 80-120 | ~150 | ~240 | ~280 | ~450 | ~600 |
Motor Power(kw) | 7.5 | 2.2 x2 | 3.7 x2 | 5.5 x2 | 7.5 x2 | 8.5 x2 |
Installation angle (0 ) | 5 | 5 | 5 | 5 | 5 | 5 |
Funnel Size (mm) | 850x3000 | 960x3600 | 1100x3800 | 1200x4200 | 1300x4900 | 1500x6000 |
Overall dimension (mm) | 3110x 1800 X1600 | 3850x1950 X1630 | 4400x2050 X1660 | 4500x2050 X1700 | 5200x2350 X1750 | 6280x2350 X2400 |
Vibrating Feeder structure
Customer site
YZO series Vibrating Feeder special motor
GAOFU company have a perfect after-sales service system and professional technology team to provide customers with prompt and thorough service. Our price are most competitive and reasonable, all order will be supplied within the stipulated period. Awaiting your first inquiry order
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
