CZ series Vibrating Vertical Conveyor for Powder material
- 10 Set / Sets per Month
- Qindao / Shanghai
- T/T Credit Card
Product Details
Condition: | New | Type: | Screw Conveyor | Material: | Stainless Steel |
Material Feature: | Heat Resistant | Structure: | Conveyor System | Load Capacity: | 1130KG |
Place of Origin: | Hainan, China | Brand Name: | Gaofu | Model Number: | CZ-Z-4, CZ-Z-4 |
Voltage: | 220V-480V |
Packaging Details
Up to export standard packing
Product Description
Vibrating Vertical Conveyor for Powder material
Do you want to transport your material easily ?
Do you want to the material is not destroyed in transportation ?
Do you want to spend the least money to buy the best transportation equipment?
Come here to see ! This machine will help you solve the above problems !
1.Description
- The machine can convey all granular, block and powder etc. solid materials(low viscosity). so it is widely used in military , machinery, chemical industry, metallurgy, mining, rubber, plastics, light industry, pharmaceuticals, food processing, grain,agriculture and animal etc. industries as a bulk material lifting equipment.
- The machine features design simple structure, easy to install and maintenance, low power consumption, small occupation, saving investment.
- The machine conveys material by down-up and up-down two ways. It can be made into an open or closed structure according to different production processing requirements. Closed conveyor can effectively prevent harmful gases and dust from spilling. According to users’ needs, changing the structure, you can transport material at the same time to accomplish cooling, drying, screening and other processes.
2.The scope of application :
- CZ series vertical lifter is applicable to materiels of powder, block and short fibre, and widely used in chemical industry ,rubber ,plastic ,madicine ,light industry,metallurgy,building materiel ,machinery ,mine ,food and other industries.The materiels not only can be lifted ,but also can be dried and cooled during the process of lifting .
3.Features:
- Reasonable and simple structure,easy maintenance,low power consumption, low noise.
- This equipment occupies very little room, and the totally sealed structure can effectively advoid the dust and the harmful gas pollution
4.Technical Parameter
Model | CZ-Z-1.5 | CZ-Z-2 | CZ-Z-2.5 | CZ-Z-3 | CZ-Z-4 |
Throughput(t/h) | 3 | 3 | 2.5 | 2.5 | 2.5 |
Conveyor Height (mm) | 930 | 980 | 1030 | 1080 | 1130 |
Diameter of spiral | 220 | 321 | 631 | 631 | 503 |
Working Frequency (times/min) | 1500 | 1500 | 1000 | 1000 | 1000 |
Power(kw) | 2×1.5 | 2×1.5 | 2×1.5 | 2×1.5 | 2×1.5 |
Supply Voltage(v) | 380 | 380 | 380 | 380 | 380 |
Rated Current(A) | 2×0.4 | 2×0.8 | 2×2.2 | 2×4.1 | 2×4.1 |
Synthetic Amplitude (mm) | -4 | -4 | -4 | -4 | -4 |
Notice : Technical parameters are subject to change without notice.
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
