US$ 7,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Model Number:
FD15C
Payment & Shipping
Payment Methods:
Port of Shipment:
wuhu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Forklift Truck 2.5TUS$ 9,000 - 12,000MOQ: 1 Set -
2 Ton Chinese Mini Truck ForkliftUS$ 7,000 - 9,500MOQ: 1 Set
-
Construction Equipment Forklift 5 TonUS$ 16,000 - 17,000MOQ: 1 Set
-
FD100 10ton Diesel ForkliftUS$ 18,000 - 20,000MOQ: 1 Set
-
Stone Forklift FD80 8Ton ForkliftUS$ 15,000 - 19,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Model Number
FD15C
Type
Powered Pallet Truck
Power Souce
Gasoline Engine
Rated Loading Capacity
1500KG
Max. Lifting Height
6m
Min. Lifting Height
3m
Fork Length
920mm
Fork Width
100mm
Overall Dimensions
2790*1230*2055mm
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Manual mini forklifts 1.5T
DETAILS
| Technical parameters | Parameter Name | Unit | FD15C | |
| Speciality | Power model | Diesel | ||
| Rated capacity | kg | 1500 | ||
| Load center | mm | 500 | ||
| Lifting height | mm | 3000 | ||
| Free lifting height | mm | 115 | ||
| Size of forks (L*W*H) | mm | 920*100*35 | ||
| Mast tilt angle(Front/Back) | . | 6/12 | ||
| Minimum turning radius | mm | 2060 | ||
| Minimum right-angle stacking aisle width | mm | 3680 | ||
| Minimum right-angle aisle width | mm | 1865 | ||
| Minimum ground clearance | mm | 105 | ||
| Overhead guard height | mm | 2040 | ||
| Front overhang | mm | 400 | ||
| performance | Max driving speed (Full load) | km/h | 14.5 | |
| Max lifting speed (Full load/Without load) | km/s | 460/500 | ||
| Max tractive force (Full load) | KN | 16 | ||
| Max grade ability | % | 20 | ||
| Size | Overall length( No forks) | mm | 2250 | |
| Overall width | mm | 1086 | ||
| Max fork lifting height(With load backrest) | mm | 3860 | ||
| Mast height | mm | 1955 | ||
| Chassis | Tyre Front wheel | mm | 6.5-10-10PR | |
| Tyre Back wheel | mm | 5.00-8-10PR | ||
| Axle base | mm | 1400 | ||
| Wheel span(Front/Back) | mm | 890/920 | ||
| Dead weight(No load) | kg | 2680 | ||
| drive | Battery | Voltage/Capacity | V/Ah | 12/90 |
| Engine | Model | XINGCHANG485BPG Or YANMAR 4TNE92 | ||
| Rated power | kw/r.p.m | 30/2600 | ||
| Rated torque | Nm/r.p.m | 131/1800 | ||
| Cylinders diameter *Stroke | mm | 85*100 | ||
| Number of cylinders | 4 | |||
| displacement | L | 2.27 | ||
| gears front/back | L | 45 | ||
| working pressure | Mpa | 14.5 | ||
For more information, free to contact us.
OTHERS :
A:date of delivery:15-25days after received the deposit
B:payment terms:T/T(30% deposit,balance paid before shipment).Or L/C at sight
C:Guaranty period: one year or 2000hours upon receiving goods.
