Stone Forklift FD80 8Ton Forklift

Qingzhou Shiji Kaiwei Construction Machinery Co., Ltd.
Stone Forklift FD80 8Ton Forklift thumbnail-1
Stone Forklift FD80 8Ton Forklift photo-1
US$ 15,000 - 19,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Model Number:
FD80
Type:
Powered Pallet Truck
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
wuhu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Model Number FD80
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 8 ton
Max. Lifting Height 6m
Min. Lifting Height 3m
Fork Length 1375 mm
Fork Width 150mm
Overall Dimensions 3800*2000*2510mm
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Stone Forklift FD80 8Ton Forklift



Specification of 8Ton Forklift

Technical parametersParameter Name UnitsFD80
FeaturesPower type  Diesel
Rated Load kg8000
Load Center mm600
Lifting Height mm3000
Free lifting Height mm200
Fork Size (L*W*T)mm1370*150*70
Mast Tilt Angle   Front/Rea 10/10
Minimum Turing Radius mm3500
Minimum Stacking Right Angle Channel Width mm3150
Minimum right angle channel width mm265
minimum turing Radius mm3500
overhead guard height mm2510
front overhang mm684
PerformanceMax.travelling speed full loadkm/h22
Max. lifting speedfull loadm/s58/27
Max. tractionfull loadkn380
Max.climbing ability %20
Dimensionoverall lengthwithout forkmm3800
overall width mm2000
Max. fork lifting height/weight(with load backrest) mm4248
Mast height mm2585
Chassistyrefrontmm8.25-20-14PR
rearmm8.25-15-14PR
wheel base mm2250
wheel treadfront/rearmm1470/1700
curb weightwithout loadkg10200
Powerbatteryvoltage/capacity (12/90)*2
enginemodel  XICHAI CA6110
rated powerKw/r/p.m83/2000
rated torqueNm/r.p.m450/1450
bore*strokemm110*125
cylinder amout 6
displacementL7.127
fuel tank volume L140
gears front/back  2/2
working pressure Mpa20



Standard Equipments for 8Ton Forklift

² Wide vision mast       ²Standard fork          ² Standard seat             ²Charging indicator

²Backrest                       ²Reversing lights     ² Reversing buzzer       ²Back-up mirror

²Light swith                   ²Light armor rack      ²Klaxon                           ²Two pieces of multi-way valve

²Engine flameout device                      ²Rear combination lamp          ²Overhead guard

²Durable tyre                 ²Timer                        ²Neutral indicator           ²Filter blocking alarm

²Lasso-parking brake ²Lifting and tilt joystick              ²Rate-limiting valve of lifting

²Drawbar pin                ²Lighting                    ²Adjustable steering wheel

²Tilt lin self-lock valve  ²Full hydraulic power steering  ²Upper intake device

² Handle                        ² Water thermometer² Tool box ² Rubber pedal pad

² Whirlwind air filter     ² Combination instrument             ² Hydraulic return filter

² Hydraulic oil suction filiter                               ² Hydraulic vernier              ² Oil pressure alarm

² Switch                           ² Brake                       ² Turing indicator



Attachments

²Side shift                ²Fork positioner            ²Tipping fork                ²String lever

²Hook                       ²Extended fork               ²Fork sleeve                ²Crane boom

²Roll clamp             ²Soft clamps1
