Construction Equipment Forklift 5 Ton

Qingzhou Shiji Kaiwei Construction Machinery Co., Ltd.

US$ 16,000 - 17,000 MOQ: 1 Set

Key Specifications

Condition:

New

Model Number:

FD50

Type:

Powered Pallet Truck

Payment & Shipping

Payment Methods:

Port of Shipment:

wuhu

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Model Number FD50

Type Powered Pallet Truck

Power Souce Gasoline Engine

Rated Loading Capacity 5000KG

Max. Lifting Height 6m

Min. Lifting Height 3m

Fork Length 1070mm

Fork Width 150mm

Overall Dimensions 3430*1490*2240mm

Certification ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

construction equipment forklift 5 ton
1.Load capacity 5t
2.3M lift height,1.07m fork,solid tyres
3.12months warranty
4. OEM

Construction Equipment Forklift 5 ton

Details

Technical parameters		Parameter Name	Unit	FD50
Speciality		Power model		Diesel
		Rated capacity	kg	5000
		Load center	mm	500
		Lifting height	mm	3000
		Free lifting height	mm	146
		Size of forks (LWH)	mm	107015055
		Mast tilt angle(Front/Back)	.	6/12
		Minimum turning radius	mm	2800
		Minimum right-angle aisle width	mm	2750
		Minimum ground clearance	mm	160
		Overhead guard height	mm	2350
		Front overhang	mm	570
performance		Max driving speed (Full load)	km/h	19
		Max lifting speed (Full load)	mm/s	380
		Max tractive force (Full load/Without load)	KN	22/18
		Max grade ability (Full load)	%	20
Size		Overall length( No forks)	mm	3430
		Overall width	mm	1490
		Max fork lifting height(With load backrest)	mm	4257
		Mast height	mm	2240
Chassis		Tyre Front wheel	mm	300-20-14PR
		Tyre Back wheel	mm	8.25-15-14PR
		Axle base	mm	2000
		Wheel span(Front/Back)	mm	1470/1700
		Dead weight(No load)	kg	6600
drive	Battery	Voltage/Capacity	V/Ah	(12/90)*2
	Engine	Model		LR4B3
		Rated power	kw/r.p.m	57/2200
		Rated torque	Nm/r.p.m	285/1300-1500
		Cylinders diameter *Stroke	mm	108*125
		Number of cylinders		4
		displacement	L	4.58
		gears front/back	L	100
		working pressure	Mpa	18.5
