US$ 9,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Model Number:
FD25
Payment & Shipping
Payment Methods:
Port of Shipment:
WUHU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2 Ton Chinese Mini Truck ForkliftUS$ 7,000 - 9,500MOQ: 1 Set -
Construction Equipment Forklift 5 TonUS$ 16,000 - 17,000MOQ: 1 Set
-
FD100 10ton Diesel ForkliftUS$ 18,000 - 20,000MOQ: 1 Set
-
Stone Forklift FD80 8Ton ForkliftUS$ 15,000 - 19,000MOQ: 1 Set
-
7T Diesel Forklift,Material Handling EquipmentNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Model Number
FD25
Type
Powered Pallet Truck
Power Souce
Gasoline Engine
Rated Loading Capacity
2500KG
Max. Lifting Height
6m
Min. Lifting Height
3m
Fork Length
1070 mm
Fork Width
122 mm
Overall Dimensions
2540*1160*1990mm
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
China forklift truck 2.5T
| Technical parameters | Parameter Name | Units | FD25C | |
| Features | Power type | Diesel | ||
| Rated Load | kg | 2500 | ||
| Load Center | mm | 500 | ||
| Lifting Height | mm | 3000 | ||
| Free lifting Height | mm | 135 | ||
| Fork Size | (L*W*T) | mm | 1070*122*40 | |
| Mast Tilt Angle | Front/Rea | 6/12 | ||
| Minimum Turing Radius | mm | 2240 | ||
| Minimum Stacking Right Angle Channel Width | mm | 4110 | ||
| Minimum right angle channel width | mm | 2010 | ||
| minimum turing Radius | mm | 110 | ||
| overhead guard height | mm | 90 | ||
| front overhang | mm | 470 | ||
| Performance | Max.travelling speed | full load | km/h | 19 |
| Max. lifting speed | full load | m/s | 490/520 | |
| Max. traction | full load | kn | 17 | |
| Max.climbing ability | % | 20 | ||
| Dimension | overall length | without fork | mm | 2540 |
| overall width | mm | 1160 | ||
| Max. fork lifting height/weight(with load backrest) | mm | 4024 | ||
| Mast height | mm | 1990 | ||
| Chassis | tyre | front | mm | 7.00-12-12PR |
| rear | mm | 6.00-9-10PR | ||
| wheel base | mm | 1600 | ||
| wheel tread | front/rear | mm | 970/970 | |
| curb weight | without load | kg | 3750 | |
| Power | battery | voltage/capacity | 12/90 | |
| engine | model | Xinchang490BPG | ||
| rated power | Kw/r/p.m | 40/2650 | ||
| rated torque | Nm/r.p.m | 162/2000 | ||
| bore*stroke | mm | 90*105 | ||
| cylinder amout | 4 | |||
| displacement | L | 2.82 | ||
| fuel tank volume | L | 60 | ||
| gears front/back | 2/2 | |||
| working pressure | Mpa | 17.5 |
As a professional manufacturer of forklift, we also can offer you customized service, the following items are optional:
♦windscreen ♦two/three full-free mast♦luxury seat♦solid tyre♦warning light♦fan♦colored tyre(white/green)customer appointed color.
