High Sorting Accuracy up to 99.99% Color Sorter Machine 480 Channels For Parboiled Rice / Millet Etc

High Sorting Accuracy up to 99.99% Color Sorter Machine 480 Channels For Parboiled Rice / Millet Etc photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Jietaizhineng
Model Number:
JTDM-CCD480
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Anhui, China
Brand Name Jietaizhineng
Model Number JTDM-CCD480
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Color sorter
5000*3 pixel
Detecting area 0.02 square millimeter
CCD Sensor :Toshiba
Valve: SMC,JIETAI

High Sorting Accuracy up to 99.99% Color Sorter Machine 480 Channels For Parboiled Rice / Millet Etc

High Sorting Accuracy  99.99% Color Sorter Machine 480 Channels For Parboiled Rice / Millet Etc

1.High quality original solenoid valve with special design 16 of two row with ultra-high precision,besides,You only need to replace the bad one and not the entire solenoid valve,service life of more than one billion times.

2.Super wide 330mm, 80 channel each chute with oxidation processing, international advanced level,more capacity and more accurate demanding color sorting.

3.Three hundred and sixty degree control to sort diverse materials,Big and small models are universal,using the triangle principle,more stable,no deformation.

4.Special damper can reduce the good material to defect chamber to improve the precision;reduce the optimized carryover and improve the processing efficiency.

5.We are professionally manufacturing color sorter machine for many years,and we supply the service for the OEM/ODM,and Agents,we hope we can build a long term cooperation and win-win relationship.





High Sorting Accuracy up to 99.99% Color Sorter Machine 480 Channels For Parboiled Rice / Millet Etc



Model

JTDM-CCD160

JTDM-CCD240

JTDM-CCD320

JTDM-CCD400

JTDM-CCD480

Throughput(T/H)

1.5~3

3~8

4~11

6~13

7~15

Channels

160

240

320

400

480

Chutes

2

3

4

5

6

Light Source

Led Light

Led Light

Led Light

Led Light

Led Light

Pixel of Camera

2048

2048

2048

2048

2048

Color Sorting Accuracy

99.99%

99.99%

99.99%

99.99%

99.99%

Carryover rate

10:1

10:1

10:1

10:1

10:1

Power(KW)

0.8-2

1.0~2.5

1.2~3.0

1.4~3.5

1.6~4.0

Air pressure(Mpa)

0.6

0.6

0.6

0.6

0.6

Voltage(v)

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

Air consumption (L/min)

800-1300

1000-1800

1200-2500

1500-3000

1800-3600

Weight(kg)

700

900

1100

1300

1500

Diamension(mm)L*W*H

1674* 1520*1800

1674* 1520*1800

1983*1520*1800

2319*1520*1800

2655*1520*1800

Package

wooden case

wooden case

wooden case

wooden case

wooden case

 Note : The above impurities is around 2% . The Specific parameters will be different based on the raw material and impurities
