Fuel saving style oil distillation plant Used motor oil recycling to diesel fraction 5ton
- 25 Set / Sets per Month
- lianyungang
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Henan, China | Brand Name: | XHZT | Model Number: | XHzl-10 |
Product Description
Main equipment list
1.Raw oil tank
This device is to store raw oil ,such as pyrolysis oil, waste engine oil,
black oil, waste lubrication oil, oil sludge etc.
2.Preheating system
This system will heat the raw oil and after heating this oil coming into disitllation reactor .this device use the hot smoke produced by dedust system ,this device can saving 1/3 fuel and saving disitllation time
3.Distillation reactor
This is the most important device , here the raw oil after preheating and go inside this reactor without stop. the reactor is horizontal ,and non-rotate when distillate oil .
this horizontal shape can giving bigger heating area then that of vertical reactor .so it can accelerate the disitllation .
tion final oil
4.Catalyst tower
This system we put catalyst chemical inside it and when distillate oil these chemical will make oil changed.
5.Distillaton tower
During distillation ,the oil will go up to certain altitude and in certain heating temperature, the altitude and temperature same important for oil change
6.Cooling device for oil
Cool oil by cool water .
The cooling system include water pool, condenser and cooling pipes and cooling tower, cooling tower is used for cooling the water inside water pool.
This cooling system’s water is recycling ,so water is recycled .
7.Final oil collection tank
These tanks used for collec
8.Safety device
This device is very important , it can keep anti-fire , it sure no backfire.
And the whole system is anti-explosion.
9. Electric Control system
This system can control the whole working system, it is easy to use. And very convenient
10.Heavy oil collection tank
Used for collection heavy oil after distillation.
oil index
Project | diesel | standard |
Oxidation stability | 2.2 | ≤2.5 mg/100ml |
Sulfur content | 0.3 | M/m≤0.2 |
10% steamed residual carbon residue | 0.33 | M/m≤0.3 |
Ash content (10%) | 0.16 | %m/m≤0.01 |
Waste content (10%) | traces | / |
Mechanical impurities | / | / |
Density (g/ml) | 0.85 | 0.83-0.87 |
Solidifying point ( ℃) | -10 | 0 |
Flash point (closed ) ( ℃) | 45 | 55 |
Movement viscosity | 3.5 | (20 ℃) mm2/s 3.0-8.0 |
Combustion value(Kcal) | 9500 | 8500 |
colority | 1.2 | ≤3.5 |
cetane number | 40 | 45 |
Acidity | / | MGkoh/100ml≤7 |
Plant data
1 | The raw materials: | Tire oil,pyrolysis oil, fuel oil,used engine oil,black oil |
2 | Out put | Base oil/diesel |
3 | Oil color | Shallow yellow/bright yellow |
4 | Daily capacity: | 5 ton /day |
6. | The size of reactor(D*L) | 1800*3000mm |
7. | Reactor material | Q345R |
8. | Final oil out rate | 85 % |
9 | Feeding way | continuous |
10 | Slag out | Auto continuous |
11 | Working area | 500-600 square meters |
12. | Cooling way | By water |
13 | Heating way | Direct/indirect |
14 | Working presure | Normal/slightly negative |
15 | Effective working temperature | 280-400℃ |
16 | Power | 12 kw |
17 | voltage | 220v/380v |
18 | Fuel to heating | Coal wood, gas oil, etc |
19. | type | Pollution free |
20. | Certificate | CE,ISO |
21 | Heating fuel | Coal .wood, gas. Oil.electric |
FOB Port (China)
FOB lianyungang port, Jiangsu Province,China!
We can also arrange port according to customer
After-sales service
(1)We will provide the foundation drawings and catalyst formular once we receive deposit
(2)installation
we wil send 1-2engineer to your local for guide installation and debugging
3)In normal use condition ,reactor warranty:3years,lifelong time5-6years!
Installlation picture
Oil before and after distillation
Plant advantages
1).This achievement essential equipment adopts the decompression; catalyzed split craft and the product chemistry extract technology.
2).Provides the environmental protection equipment is perfect. For instance waste gas burner and smoke dust removal room.
3).Adopts the simple chemistry method, has solved the product color and the unusual smell.
4).The oil extraction rate of the pure crude oil is not lower than 80%
5).This equipment design is reasonable, manufacture craft is advanced, high automatically, and the complete safety equipment .
Payment term and delivery:
1. ) Payment term: 30% TT advance payment 70%TT payment before plant shifting
2. ) Delivery time: for batch type plant, loading plant within 20days after getting your advance payment, for fully continuous plant, loading plant within 50days
3. ) About installation: we will send technician for guiding installation and test machine and training your workers for free. The Installation period is one months, buyers offer round tickets and accommodation for our technician.
4. ) Warranty: The whole set plant warranty period is one year (easy-ware parts except). The reactor warranty is 3 years. We will not be responsible for problems caused by personal wrong operation
5. )Quotation period :30 days
Why it is fuel saving type?
A. firstly it is fully continuous plant can continuously working 24hours and 360days withthout stop
so no need coold day reactor and start to heating again for next batch
B, we have preheating system, this system can heating raw oil before oil go into distillation reactor
in this way, it saving fuel and saving working time,
what is more the preheating system use the dust hot smoke produced by fuel burning to heating disitllation reactro , that means the preheating energy is coming from dedust sytsem ,but not extra fuel heating .
C. waste gas burning sytem, this system, reused the non-liquid gas , during disitllation system, there will be non-liquid gas produced, this oil gas will be reused agian by the waste gas burning system to heating disitllaiton reactor .
D. up-dated and reasonable design of reactor , to save fuel and save working time.
