Help CenterContinuous Pyrolysis Oil Refinery Fuel Oil Distillation Plant 10-15tpd
Related Products
-
Environmental Distillation Equipment for Pyrolysis Oil Refining From Waste TyresUS$ 38,000 - 48,000MOQ: 1 Set -
Furnace Oil Refinery Equipment Recycling Oil From Scrap Tire/plastic/rubberUS$ 58,000 - 98,000MOQ: 1 Set
-
Good Performance Oil Purifier Type Refinery Used Oil Distillation Plant 15TPDUS$ 60,000 - 95,000MOQ: 1 Set
-
Energy Saving Green Tech Continuously 10TPD Engine Oil Distillation PlantUS$ 55,000 - 85,000MOQ: 1 Set
-
2016 Up-dated Tech New Condition Waste Oil Recovery Distiller 5 TPD Oil Refining PlantUS$ 35,000 - 55,000MOQ: 1 Set
1.Technical parameter
NO. |
Name |
Parameter |
1 |
The raw materials: |
Fuel oil /waste machine oil / transformer oil/waste lube |
2 |
Out put |
Base oil |
3 |
Daily capacity: |
15 ton /day |
4 |
The size of reactor(L*W*H) |
4300*2200*2750mm |
6. |
Reactor material |
Q345R |
7. |
Final oil out rate |
75-85 % |
8. |
Feeding way |
continuous |
9 |
Slag out |
Auto continuous |
10 |
Working area |
500-600 square meters |
11 |
Cooling way |
By water |
12. |
Heating way |
Direct/indirect |
13 |
Working presure |
Normal/slightly negative |
14 |
Effective working temperature |
200-400℃ |
15 |
Power |
15kw |
16 |
voltage |
220v/380v |
17 |
Fuel to heating |
Coal wood, gas oil, etc |
18 |
type |
Pollution free |
19. |
certificate |
CE.IS |
2.Work flow:
3.Plant features:
1.)Continuous operating for 90 days without coking.
2).Latest tubular heating system which can save fuel 20--30%.
3).All sealed and auto feeding and slag discharging system, available in 350degree temperature condition.
4.)This model is for processing waste engine oil into diesel oil.
5.)The output should be above 90%, water percent affect the data obviously.
Our distillation machine can distillate the flowing materials, turn the waste to energy.
- Fuel oil extracted from waste plastics and scrap rubber.
- Waste engine oil.
- Waste raw oil.
- Waste washing oil.
- Waste oil, Raw oil.
- Waste lubricating oil.
6).Increase oil yield 5% compared to the similar plant, oil yield rate reaches to 80%.
7.)Unique condensers and vacuum device makes our pyrolysis oil distillation machine highly efficient.
8). Advanced device and design to make sure the distillation process is proceeding in a total environmental and safe surrounding.
9). Multiple methods to eliminate color and odor of the distilled oil which ensures the final oil is of high quality.
10.) The complete set of unit produce no smoke and no smell.
4.Payment term and condition:
1.) Payment term: 30% TT advance payment 70%TT payment before plant shifting .
2. ) Delivery time: for batch type plant, loading plant within 20days after getting your advance payment, for fully continuous plant, loading plant within 50days
3. )About installation: we will send technician for guiding installation and test machine and training your workers for free. The Installation period is one months, buyers offer round tickets and accommodation for our technician.
4. ) Warranty: The whole set plant warranty period is one year (easy-ware parts except). The reactor warranty is 3 years. We will not be responsible for problems caused by personal wrong operation
5 )Quotation period :30 days
6.oil afater disitllation
6.Our factory:
professional manufacturer engaged in the research, development, production, sale and service of Environmental machines, waste tire/rubber/plastic pyrolysis equipment, waste oil distillation machines, etc.
We have rich experience(8 years experience) in making and installation shangqiu harmony is the top 10 enterprise in disposing waste rubber and plastic.
Now our new tech is crude oil refining and city life trash recycling.
Which convert waste to energy without pollution .
