1. Original structure and advanced technical design
2. High screening efficiency
3. High capacity
4. Easy to maintain
5. Long service life
6. Low noise
7. All products through the ISO certification
YA, SZZ shaker widely used in mining, smelting, building material, highway, railway, water conservancy and chemical industry and many other sectors of the medium-grained materials, grading, dewatering, de-de or referred mud and operations. This series of vibrating screen features are: simple structure, reliable operation and maintenance convenience, the user hanging when ordering please specify type and seat type
Model | Screen Layers | Screen Area | Feed size | Capacity | Opening size | Frequency | Power | Weight |
Layers | m2 | mm | t/h | mm | r/min | kw | Kg | |
600/1200 | 1 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 350 |
600/1200 | 2 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 360 |
900/1800 | 1 | 1.62 | 60 | 20-25 | 1-25 | 1000 | 2.2 | 550 |
900/1800 | 2 | 1.62 | 60 | 20-30 | 1-25 | 1000 | 3 | 620 |
1250/2500 | 1 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1100 |
1250/2500 | 2 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1300 |
1500/3000 | 1 | 4.5 | 150 | 220 | 5-40 | 800 | 7.5 | 2100 |
1500/3000 | 2 | 4.5 | 150 | 250 | 5-40 | 800 | 7.5 | 2300 |
1800/4800 | 1 | 7.5 | 200 | 450 | 6-50 | 360 | 15 | 6000 |
1800/4800 | 2 | 7.5 | 200 | 500 | 6-50 | 360 | 15 | 6300 |
