Help CenterLaboratory Mixing Bucket/ Small Size Leaching Agitation Tank/Laboratory Mixing Bucket/Laboratory Slurry Conditionging Drum
Related Products
-
Mineral Technology Consultation/Technique Of Preparing/Dressing Machine/Concentrating Machine/Ore Dresser MachineUS$ 1 - 9,000MOQ: 1 Set -
Chute/Sluice/Slate Chute/Slime Separator/Specific Gravity Separation/Gravity Spiral Chute/ Gravity Spiral Sluice/Gravity SpiralUS$ 1 - 9,000MOQ: 1 Set
-
Agitation Tank/ Agitation Vat/Agitating Vessel/Washing Trommel/ Leaching Tank/Stirrer/Impeller Leaching Agitation TankUS$ 1 - 9,000MOQ: 1 Set
-
Leaching Agitation Tank/Agitation Tank/ Agitation Vat/Agitating Vessel/Washing Trommel/ Leaching Tank/Stirrer/Impeller LeachinUS$ 1 - 9,000MOQ: 1 Set
-
Washing Trommel/ Leaching Tank/Stirrer/Impeller Leaching Agitation Tank/Mix Leaching Tank/Mineral Mixing TankUS$ 1 - 9,000MOQ: 1 Set
1. Frequency control and temperature control device
2. Energy conservation and environment protection
3. All products through the ISO certification
Agitating tank is suitable for labs in industries to we agitate slurry materials, allowing ore particles to suspend and to fully contact with reagent before being mixed evenly and creating conditions for separating operation. Leaching tank is used for wet leaching agitation with central aeration, step less adjustment of inverter and other features. XJT (XDF) second-generation new product with a frequency control and temperature control devices and other characteristics (temperature less than 100 degrees)
Model | Volume of tank | Impeller diameter | Size of tank | Impeller speed | Power | Overall dimensions | Weight |
L | mm | mm | r/min | w | mm | kg | |
XJT(XDF)1.5L | 1.5 | 31 | 130/157 | 950 | 180 | 300/500/633 | 30 |
XJT(XDF)3L | 3 | 39 | 164/193 | 1400 | 180 | 300/500/633 | 35 |
XJT(XDF)5L | 5 | 48 | 190/90 | 1750 | 180 | 300/500/633 | 40 |
XJT(XDF)10L | 10 | 64/116 | 240/300 | 1600 | 550 | 350/550/770 | 43 |
XJT(XDF)15L | 15 | 64/116 | 246/348 | 1200-1500 | 550 | 480/329/910 | 45 |
XJT(XDF)30L | 30 | 64/128 | 296/448 | 1200-1500 | 750 | 560/388/960 | 63 |
XJT(XDF)130L | 130 | 150 | 500/750 | 1000 | 1500 | 720/720/1670 | 150 |
XJT(XDF)160L | 160 | 150 | 500/1000 | 600 | 1500 | 930/930/2010 | 186 |
XJT(XDF)300L | 300 | 200 | 750/750 | 800 | 1500 | 1180/1180/1766 | 297 |
