The spiral chute
1. Simple structure
2. Easy maintain
3. Reasonable structure
4. Less space and simple fixed
5. Energy conservation and environment protection
6. All products through the ISO certification
BLX-type rotary spiral chute is applicable for separation of fine-grained (including micro-grained) metallic minerals such as iron, ilmenite, chrome, tungsten-tin ore, niobium-tantalum ore, gold placer, seashore monazite, rutile and zircon as well as other metallic and non-metallic minerals with adequate difference of specific gravity.
Rotating spiral chute is a combination of spiral concentrator, shaking, centrifugal concentrator, spiral chute features, mainly by the rack, chute, then mine shafts, and drives four major components.
The device is small footprint, power consumption is small, has enriched a small amount of water is high and high recovery rate, easy operation, etc....
Model |
Diameter |
Pitch |
Spiral number |
speed |
Feed size |
Feed density |
Capacity |
Overall dimensions |
power |
Weight
|
mm |
mm |
number |
r/min |
mm |
% |
t/h |
mm |
kw |
Kg |
|
940 |
940 |
500 |
2 |
20-26 |
0.6-0.05 |
30-45 |
2-3 |
1100/1000/3600 |
1.1 |
600 |
1200 |
1200 |
720 |
2 |
12-18 |
0.6-0.05 |
30-45 |
6-8 |
1360/1360/5600 |
2.2 |
800 |
